EVGA ACX 2.0+ coolers are 26% cooler than reference, giving you the coolest and highest performance possible.
100%






Make informed decisions with expert advice. Learn More
EVGA ACX 2.0+ coolers are 26% cooler than reference, giving you the coolest and highest performance possible.
EVGA's ACX 2.0+ fan turns off below 60°C, generating absolutely no noise during medium load, and whisper silent operating during gaming.
EVGA ACX 2.0+ fans use double ball bearings, which offer a 4X longer lifespan than competitors.
EVGA ACX 2.0+ fans use 4X lower power than competitors, unlocking additional power for the GPU and allowing better and more stable overclocks.
EVGA's power target (max power headroom) is precisely tuned for the perfect balance of thermal, power and performance, offering up to an increase of 33%.
EVGA's straight heat pipes offer better heat dissipation by 6% when compared to competitors bent heat pipes, for the coolest and highest performing graphics card.
EVGA's full size cooling plate makes direct contact with the memory and VRM (Voltage regulators) reducing memory temperature by up to 14% and VRM's by up to 47%.
EVGA PrecisionX 16
EVGA PrecisionX 16 software (included with the card) is one of the world's most popular overclocking applications with robust features and monitoring capabilities. It is also the ONLY overclocking application to offer full DirectX 12 OSD support!
EVGA GRAPHICS CARD | PART NO. | BASE/BOOST CLOCK | BIOS | COOLER | POWER CONNECTOR | POWER PHASE | MAX POWER DRAW | PERFORMANCE | BACKPLATE |
EVGA GeForce GTX 980 Ti K|NGP|N ACX 2.0+ | 06G-P4-5998 | 1203/1304 | Triple | ACX 2.0 | 8+8+6-Pin | 14+3 | 300W | Ultra Extreme | Yes |
EVGA GeForce GTX 980 Ti HYDRO COPPER GAMING | 06G-P4-4999 | 1140/1228 | Single | Waterblock | 8+6-Pin | 6+2 | 250W | Extreme Water | Yes |
EVGA GeForce GTX 980 Ti HYBRID GAMING | 06G-P4-1996 | 1140/1228 | Single | Hybrid Cooler | 8+6-Pin | 6+2 | 250W | Extreme Water | Yes |
EVGA GeForce GTX 980 Ti CLASSIFIED GAMING ACX 2.0+ | 06G-P4-4998 | 1190/1291 | Double | ACX 2.0+ | 8+8-Pin | 14+3 | 300W | Ultra | Yes |
EVGA GeForce GTX 980 Ti FTW GAMING ACX 2.0+ | 06G-P4-4996 | 1190/1291 | Double | ACX 2.0+ | 8+8-Pin | 8+2 | 275W | Ultra | Yes |
EVGA GeForce GTX 980 Ti SC+ GAMING ACX 2.0+ | 06G-P4-4995 | 1102/1190 | Single | ACX 2.0+ | 8+6-Pin | 6+2 | 250W | Extreme | Yes |
EVGA GeForce GTX 980 Ti SC GAMING ACX 2.0+ | 06G-P4-4993 | 1102/1190 | Single | ACX 2.0+ | 8+6-Pin | 6+2 | 250W | Extreme | Optional |
EVGA GeForce GTX 980 Ti GAMING ACX 2.0+ | 06G-P4-4991 | 1000/1076 | Single | ACX 2.0+ | 8+6-Pin | 6+2 | 250W | Great | Optional |
EVGA GeForce GTX 980 Ti SC GAMING | 06G-P4-4992 | 1102/1190 | Single | Single Fan | 8+6-Pin | 6+2 | 250W | Better | Optional |
EVGA GeForce GTX 980 Ti GAMING | 06G-P4-4990 | 1000/1076 | Single | Single Fan | 8+6-Pin | 6+2 | 250W | Good | Optional |
Pros: EVGA support was available at 11pm EST and was very helpful unlike ASUS who for 4 days did not answer their motherboard support phones (or disconnected me when they did before I could talk to someone) and when I finally got someone on chat support was told that the 980ti was not supported because its not on the QVL...to which I replied neither are any modern graphics cards! Asus support then told me it was supported and then ended the chat abruptly.....so I will not be buying an ASUS card as an alternative simply because EVGAs Support was superior.
Cons: Failed out of the box, prevented Asus impact VI motherboard from posting. The dead card allowed my EVGA SR2 motherboard to post but without display thus confirming the graphics card fault
Overall Review: I was replacing an EVGA 780ti for an EVGA 980ti and have wasted 5 days of my time. I have submitted a replacement order with Newegg but my faith in EVGA has gone down even further than it did when they EVGA refused to honor my lifetime warranty on my EVGA SR2 motherboard. I really hope the new card works out. Btw the backplane does not perform any function. There are heat sink pads which do not attach to anything because it is the same back pland as the titan X which has ram on the back of the card whereas the 980ti does not....so if you can get the 980ti card without the backplane for less go with that solution
