$179.98
Ships from China.
Meet Your Seller
GIGABYTE GA-890FXA-UD7 AM3 AMD 890FX USB 3.0 XL ATX AMD Motherboard
Used - Very Good Product Type
- AMD 890FX
- Phenom II / Athlon II / Sempron
- DDR3 1866(OC)*/1333/1066 *To reach DDR3 1866MHz or above, you must install two memory modules and install them in the DDR3_3 and DDR3_4 memory sockets.
+
+
Specs
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the GIGABYTE GA-890FXA-UD7
| Brand | GIGABYTE |
|---|---|
| Model | GA-890FXA-UD7 |
| CPU Socket Type | AM3 |
|---|---|
| CPU Type | Phenom II / Athlon II / Sempron |
| FSB | 2600 MHz |
| Chipset | AMD 890FX |
|---|---|
| South Bridge | AMD SB850 |
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 1866(OC)*/1333/1066 *To reach DDR3 1866MHz or above, you must install two memory modules and install them in the DDR3_3 and DDR3_4 memory sockets. |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2) (Note 1) 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2) (Note 1) 2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2) (Note 2) (Note 1) The PCIEX8_1 slot shares bandwidth with the PCIEX16_1 slot and the PCIEX8_2 slot with PCIEX16_2. The PCIEX16_1/PCIEX16_2 slot will operate at up to x8 mode when the PCIEX8_1/ PCIEX8_2 is populated. (Note 2) The default bandwidth for the PCIEX4_2 slot is x1. When it is configured to x4 mode, the onboard GSATA2_6, GSATA2_7, and IDE connectors will become unavailable because they share bandwidth with the PCIEX4_2 slot. (Refer to Chapter 2, "Integrated Peripherals" in manual for how to change the operating bandwidth for the PCIEX4_2 slot.) |
|---|---|
| PCI Slots | 1 x PCI Slot |
| PATA | 1 x ATA133 2 Dev. Max |
|---|---|
| Serial ATA (SATA) | 6 x SATA 6Gb/s |
| SATA RAID | SATA 6Gb/s: SATA RAID 0, RAID 1, RAID5, RAID 10 and JBOD SATA 3Gb/s: SATA RAID 0, RAID 1, and JBOD |
| Onboard Video Chipset | None |
|---|
| Audio Chipset | Realtek ALC889 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8111D |
|---|---|
| Second LAN Chipset | Realtek 8111D |
| Max LAN Speed | 2 x 1Gbps |
| Back I/O Ports | 1 x Optical S/PDIF Out / 1 x PS/2 / 1 x S/PDIF Coaxial Out / 2 x USB 3.1 Gen 1 / 6 x Audio Jacks / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 1 |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 6 x USB 2.0 |
| IEEE 1394 | 2 x IEEE 1394a |
| eSATA | 2 x eSATA/USB Combo connectors |
| S/PDIF Out | 1 x Optical, 1 x Coaxial |
| Audio Ports | 6 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x 1394a |
| Form Factor | XL ATX |
|---|---|
| Dimensions (W x L) | 12.8" x 9.6" |
| Power Pin | 24 Pin |
| Features | Supports new generation of AMD Phenom II X6 processors Supports newest NEC SuperSpeed USB 3.0 with superfast transfer rates of up to 5 Gbps 3X USB power delivery for greater compatibility and extra power for USB devices Provides newest Marvell SE9128 high speed SATA3 storage interface with superfast 6Gbps link speed Advanced 8+2 phase CPU VRM power design for AMD high-TDP 140W CPU support 3 PCI-E 2.0 x16 graphics interface with ATI CrossFireX support Smart DualLAN with Intelligent LAN port auto-switching Power/reset/Clr CMOS onboard button for easily operation on the workbench The Precision OV provides more precision voltage control for system |
|---|
| First Listed on Newegg | May 16, 2025 |
|---|
