Question 1

Can I use a Pentium Dual Core 2.0 GHz processor in this motherboard?

Accepted Answer

You need to be more specific then "Pentium" Dual Core. This board will handle Pentium 4 Processors that are built for Socket LGA 775. It was built for Core 2, Core 2 duo, Core 2 Extreme, Core 2 Quad Chips and can handle some quad cores. I am currently running a Core 2 duo E7600 @ 3.06 ghz. Intel has compatibility charts for certain chip-sets you can look up on their website, search for "DG41WV" which is the OEM version of this board.

Question 2

Is this windows 7 64 bit compatible?

Accepted Answer

It functions flawlessly using Windows 8.1 Pro (64 bit) then after down loading all of the updates I upgraded to Windows 10 Pro (64 bit) and again it works flawlessly. I jumped from Windows Vista to Windows 8.1 then 10. Windows 10 is more like Vista than 8.1, I think it is more intuitive and a nice move by Windows, can't beat the free upgrade to 10 either.

Question 3

will the G.SKILL Value Series 8GB F3-10600CL9D-8GBNT work with the GIGABYTE GA-G41MT-S2PT motherboard, it is double sided or dual ranked memory like other reviews say that do work on it?

Accepted Answer

G.SKILL Value Series 8GB (2 x 4GB) 240-Pin DDR3 SDRAM DDR3 1333 (PC3 10666) Desktop Memory Model F3-10666CL9D-8GBNT (Can get at Newegg)

and

Crucial's 8GB Kit (4GBx2) DDR3 PC3-12800 Unbuffered NON-ECC 1.5V 512Meg x 64  (Can not get at Newegg, can get at Crucial)

I'm using the GSkill which works fine on my GA-G41MT-S2PT (Rev 2.1) motherboard.

Question 4

Does this motherboard have AHCI support?

Accepted Answer

No, IDE only.  It also is VERY particular about what memory will work when you use more than 2GB per slot.

Question 5

What rev is this?

Accepted Answer

it's printed on the board. usually in white letters. if you don't find it assume it is revision 1

Question 6

What brand of RAM (4GB Sticks) will work with this board? I found out the hard way that Kingston 4GB sticks don't work. Is there any brand other than Samsung, AMD and Apacer that works?
Thanks

Accepted Answer

I bought this board in 2013, and this RAM worked with it: http://www.newegg.com/Product/Product.aspx?Item=N82E16820231307 G.SKILL Ripjaws Series 4GB 240-Pin DDR3 SDRAM DDR3 1066 (PC3 8500) Desktop Memory Model F3-8500CL7S-4GBRL Also, I have always had a good RAM compatibility when using Crucial sticks.

Question 7

what is the max memory ram it supports?

Accepted Answer

8GB, but you can only use certain 4GB Sticks, none of which are in production any longer. I found some on a website that wanted over $100.00 each stick. Not worth it. Buy and ASUS board with a 1150 socket and upgrade to an i7. Best decision I ever made.

Question 8

I'm unable to load Windows 7. It boots fine, considering it won't let my QX6850 run at 3.66GHz. I get the  "everything's fine" single beep. When I boot from HDD, the Windows logo appears, freezes, the monitor blue screens, then the MoBo reboots. When it's ready to load Win 7 again it shows error recovery screen with timed out option.

The keyboard is dead at this point so I can't choose from 1- startup recovery or 2- start windows like normal. After startup repair finishes, it says no problems were found. Even with my back up USB plugged in and I use system restore and then reboot. the blue screen happens again and everything repeats. I saw something briefly before rebooting from repair mode  about a bad driver. I can't get into the OS to fix that though. Any suggestions?

Accepted Answer

I went to Gigabyte's webpage and looked at the support information for that model motherboard.  I don't see a QX6850 listed in the supported processors for that model.  The closest thing I see is an X6800.  You might need to find a processor that appears on that list and try again.  I've had good luck with a Q9595 and also with a Q8300.

Question 9

is it possible to hook up a usb3.0 cable to this board?

Accepted Answer

Yes, if you install a usb3 adapter card.  There are only two sockets on the board.  I needed 3 (video card, usb3 adapter card, and creative sound card), so I did not use the motherboard.  It should work for you if you get your sound with other options on the motherboard.

Question 10

I need to replace my out of production GA-EG41M-S2H. Will there be any software compatibility issues with newer mobo?

Accepted Answer

The motherboard works with windows XP, 7, 8.1 and 10.  I have also used LINUX with this motherboard.
Software compatibility should be the same, but it is impossible to tell until you try ALL YOUR SOFTWARE PROGRAMS...

Memory is different, I believe your current motherboard the GA-EG41M-S2H uses DDR2 memory, the Gigabyte GA-G41MT-S2PT LGA 775 Motherboard uses DDR3 memory.
If that is a problem Newegg also sells the ASRock G41C-GS R2.0 LGA 775 Intel G41 + ICH7 Intel this motherboard uses either DDR2 or DDR3 memory. Hope this helps.

CPU Socket Type	LGA 775
CPU Type	Intel Core 2 Extreme / Core 2 Quad / Core 2 Duo / Pentium / Celeron
FSB	1333/1066/800MHz

Number of Memory Slots	2x240pin
Memory Standard	DDR3 1333 (O.C.)/1066/800
Maximum Memory Supported	8GB
Channel Supported	Dual Channel

PCI Express x16	1 x PCI Express x16
PCI Express x1	1 x PCI Express x1
PCI Slots	2 x PCI Slots

LAN Chipset	Realtek 8111E
Max LAN Speed	1Gbps

Back I/O Ports	2 x PS/2 / 4 x USB 2.0/1.1
PS/2	2
COM	1
LPT	1
Video Ports	D-Sub
USB 1.1/2.0	4 x USB 2.0
Audio Ports	3 Ports

Meet Your Seller

GIGABYTE GA-G41MT-S2PT LGA 775 Intel G41 + ICH7 Micro ATX Intel Motherboard

Used - Very Good

Learn more about the GIGABYTE GA-G41MT-S2PT

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Onboard USB	4 x USB 2.0
Other Connectors	1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x clearing CMOS jumper

Form Factor	Micro ATX
Dimensions (W x L)	9.6" x 7.64"
Power Pin	24 Pin

Item#: 9SIAWFGKF20316
