EVGA GeForce GTX 1080 Ti 11GB GDDR5X PCI Express 3.0 SLI Support Graphics Card 11G-P4-6696-RX

REFURBISHED Product Type
(2) Write a Review
  • 11GB 352-Bit GDDR5X
  • Core Clock 1569 MHz
  • Boost Clock 1683 MHz
  • 1 x Dual-Link DVI-D 1 x HDMI 2.0b 3 x DisplayPort 1.4
  • 3584 Cores CUDA Cores
  • PCI Express 3.0
Specs
Reviews (2)

Learn more about the EVGA 11G-P4-6696-RX

Model
Brand EVGA
Model 11G-P4-6696-RX
Interface
Interface PCI Express 3.0
Chipset
Chipset Manufacturer NVIDIA
GPU Series NVIDIA GeForce GTX 10 Series
GPU GeForce GTX 1080 Ti
Core Clock 1569 MHz
Boost Clock 1683 MHz
CUDA Cores 3584 Cores
Memory
Effective Memory Clock 11016 MHz
Memory Size 11GB
Memory Interface 352-Bit
Memory Type GDDR5X
3D API
DirectX DirectX 12
OpenGL OpenGL 4.6
Ports
Multi-Monitor Support 4
HDMI 1 x HDMI 2.0b
DisplayPort 3 x DisplayPort 1.4
DVI 1 x Dual-Link DVI-D
Details
Max Resolution 7680 x 4320
SLI Support SLI Ready
Virtual Reality Ready Yes
Cooler Triple Fans
Operating Systems Supported Windows 10 32/64-bit, Windows 8 32/64-bit, Windows 7 32/64-bit
Thermal Design Power 250W
System Requirements 600 Watts or greater power supply.
PCI Express, PCI Express 2.0 or PCI Express 3.0 compliant motherboard with one graphics slot.
Power Connector 2 x 8-Pin or 6+2-Pin
Dual-Link DVI Supported Yes
HDCP Ready Yes
Features
Features Simultaneous Multi-Projection

VR Ready

NVIDIA Ansel

NVIDIA SLI w/ HB Bridge Support

NVIDIA G-SYNC

NVIDIA GameStream

NVIDIA GPU Boost 3.0

Microsoft DirectX 12 API

Vulkan API

OpenGL 4.6 Support

Max Digital Resolution - 7680x4320

HDMI 2.0b, DisplayPort 1.4 and Dual-Link DVI

Built for EVGA Precision XOC

Asynchronous Fans

9 additional temp sensors to monitor Memory and VRM

GPU / Memory / PWM Thermal Status Indicator LEDs

New vented heatsink fin design and pin fins for optimized airflow

Safety fuse to protect components from damage due to improper installation or other component failures

Redesigned cooling with L-shaped contact fins to improve contact surface area for better heat dissipation

EVGA iCX Technology
Form Factor & Dimensions
Max GPU Length 300 mm
Card Dimensions (L x H) 11.80" x 5.62"
Slot Width 2 Slots
Additional Information
Date First Available October 11, 2018
