Kramer 18G 4K Presentation Switcher/Scaler with HDBaseT & HDMI Simultaneous Outputs VP-440X (87-00002090)
+
+
Specs
Reviews
Learn more about the Kramer Electronics VP-440X (87-00002090)
| Brand | Kramer |
|---|---|
| Model | VP-440X (87-00002090) |
| Video | Max. Resolution: 4K@60Hz (4:4:4) Max Data Rate: 18Gbps (6Gbps per graphic channel) Standards Compliance: HDCP 1.4 & 2.2. Supports HDR10 Input Resolutions HDMI: 480i/576i, 480p/576p, 720p@60/50Hz, 1080i@60/50Hz, 1080p@60/50Hz, 1080p@24/25/30Hz, 640x480@60/67/72/75/85Hz, 800x600@56/60/72/75Hz, 1024x768@60/70/75Hz, 1280x1024@60/75Hz, 1280X960@60Hz, 1280X720@60Hz, 1920X1080@60Hz, 1600X1200@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1600X900@60Hz RB, 1680x1050@60Hz, 1920x1200@60Hz RB, 2048x1080@24/25/30/50/60Hz, 4K/2K@24/25/30/50/60Hz, 4K/2K(4:2:0)@50/60Hz Input Resolutions VGA: 640x480@60/67/72/75/85Hz, 800x600@56/60/72/75Hz, 1024x768@60/70/75Hz, 1280x1024@60/75Hz, 1280X960@60Hz, 1280X720@60Hz, 1920X1080@60Hz, 1600X1200@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1400x1050@60Hz, 1600X900@60Hz RB, 1680x1050@60Hz, 1920x1200@60Hz RB Output Resolutions: 640x480@60Hz, 800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1400x1050@60Hz, 1440x900@60Hz, 1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz RB, 1920x1080@60Hz, 1280x720@60Hz, 720x480p@60Hz, 720x576p@50Hz, 1280x720p@50/60Hz, 1920x1080p@24/25/30/50/60Hz 4K Output Resolutions - HDMI: 4K@24/25/30/50/60Hz (4:4:4) 4K Output Resolutions - HDBaseT: 4K@24/25/30Hz (4:4:4), 4K@50/60Hz (4:2:0) Switching Time Between Inputs: 3 seconds Video Latency: 1-2 frames |
|---|
| HDMI | INPUTS: 4 HDMI: On female HDMI connectors OUTPUTS: 1 HDMI: On a female HDMI connector |
|---|---|
| Network Interface | 1 Ethernet: On an RJ-45 female connector |
| USB Port | 1 USB: On a female USB-A connector for firmware upgrade |
| VGA | INPUTS: 1 VGA: On a 15-pin HD connector |
| Analog Aduio | INPUTS: 5 Stereo Analog Unbalanced Audio: On a 3.5mm mini jack OUTPUTS: 1 Stereo Analog Unbalanced Audio: On a 3.5mm mini jack |
| Other Connector | INPUTS: 1 Microphone: On a 6.3mm jack OUTPUTS: 1 HDBaseT: On an RJ-45 connector PORTS: 1 DATA RS-232: On a 3-pin terminal block for serial link extension 1 CTRL RS-232: On a 3-pin terminal block for device control 6 Contact Closure Switches: On a 7-pin terminal block connector |
| Power Consumption | 18-19W |
|---|---|
| Power Supply | 5V DC, 4A |
| Specification | EXTENSION LINE: Compliance: HDBaseT 1.0 Up to 40m (130ft): At 4K@60Hz (4:2:0) Up to 70m (230ft): At full HD (1080p @60Hz 24bpp) Note: When using Kramer HDBaseT cables ENCLOSURE: Cooling: Convection ventilation Type: Aluminum Size: 1/2 19" ENVIRONMENTAL CONDITIONS: Operating Temperature: 0° to +40°C (32° to 104°FHz) Storage Temperature: -40° to +70°C (-40° to 158°FHz) Humidity: 10% to 90%, RHL non-condensing |
|---|
| Feature | 4 HDMI inputs Supports up to 4K@60 4:4:4 on the HDMI output Supports up to 4K@60 4:2:0 on the HDBaseT output HDBaseT Max. Range: 70m (230ft) at 1080p, 40m (130ft) at 4K@60Hz (4:2:0) Analog audio and microphone embedding CEC Support for display ON/OFF Upscales and downscales to / from all resolutions |
|---|
| Dimensions | 8.45" x 6.42" x 1.72" |
|---|---|
| Weight | 2.40 lbs. |
| Package Content | Included: Power adapter, rubber feet |
|---|
| Date First Available | April 04, 2022 |
|---|
