SICK WLL190T-2N432 Fiber-optic Photoelectric Sensor ,NPN New
- SICK WLL190T-2N432 Fiber-optic Photoelectric Sensor ,NPN New
+
+
Overview
Specs
Reviews
FEATURES Device type Stand-alone Sensor/ detection principle Fiber-optic photoelectric sensor Dimensions (W x H x D) 10.5 mm x 34.8 mm x 76.5 mm Housing design (light emission) Rectangular Sensing range max. 0 m... 4 m, Through-beam system 1) 2) Sensing range 0 mm... 480 mm, Proximity system 3) 4) 0 m... 2 m, Through-beam system 5) Focus 6) Type of light Visible red light Light source LED 7) Angle of dispersion Approx. 65° 6) Wave length 650 nm Adjustment Menu-controlled Single teach-in button Cable Time type Without time delay Off delay On delay One shot Delay time Programmable, 0 ms, 9, 999 ms Indication Display Display LED status display / 2x 4-character digital dual displays, Set value (green indicator) and actual value (red indicator) are displayed simultaneously, display of parameters MECHANICS/ELECTRONICS Supply voltage 10 V DC.
.. 24 V DC 1) Ripple = 10 % 2) Power consumption = 50 mA Switching output NPN 3) 4) Switching mode Light/dark switching 3) 4) Switching mode selector Manually selectable Output current Imax. = 100 mA Response time = 2 ms, = 60 µs, = 250 µs 5) Switching frequency 8, 333 Hz 2, 000 Hz 250 Hz Connection type Cable, 4-wire, 2 m 6) Cable material PVC Conductor cross-section 0.2 mm2 Circuit protection A 7) B 8) C 9) D 10) Protection class III Weight 20 g Housing material Plastic, ABS/PC Enclosure rating IP66 11) Ambient operating temperature –25 °C.
.. +55 °C 12) Ambient storage temperature –40 °C... +70 °C
.. 24 V DC 1) Ripple = 10 % 2) Power consumption = 50 mA Switching output NPN 3) 4) Switching mode Light/dark switching 3) 4) Switching mode selector Manually selectable Output current Imax. = 100 mA Response time = 2 ms, = 60 µs, = 250 µs 5) Switching frequency 8, 333 Hz 2, 000 Hz 250 Hz Connection type Cable, 4-wire, 2 m 6) Cable material PVC Conductor cross-section 0.2 mm2 Circuit protection A 7) B 8) C 9) D 10) Protection class III Weight 20 g Housing material Plastic, ABS/PC Enclosure rating IP66 11) Ambient operating temperature –25 °C.
.. +55 °C 12) Ambient storage temperature –40 °C... +70 °C
