Ubiquiti U7 In-Wall, Wall-mounted WiFi 7 Access Point with 4 spatial streams and an integrated 2.5 GbE PoE switch
- Coverage: 115 m² (1,250 ft²)
- Max. Client Count: 200+
- WiFi Standard: WiFi 7
- Built-In Switch: (1) PoE+ input and (1) PoE output
+
+
Specs
Reviews
Learn more about the Ubiquiti Networks U7 In-Wall
| Brand | Ubiquiti Networks |
|---|---|
| Model | U7 In-Wall |
| Part Number | U7-IW |
| # of Users | 200+ |
|---|---|
| Standards | WiFi 7 |
| WiFi Generation | Wi-Fi 7 |
| Wireless Data Rates | 802.11be (WiFi 7) 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) 802.11ac (WiFi 5) 6.5 Mbps to 1.7Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| Mounting Location | Indoor |
| Operating Range | Indoor: Up to 115m, Outdoor: Up to 115m |
| Multiple SSIDs | Max. BSSIDs 8 per Radio |
| MIMO | 5 GHz 2 x 2 (DL/UL MU-MIMO) 2.4 GHz 2 x 2 (DL/UL MU-MIMO) |
| Power Supply | PoE |
| Max Power Consumption | 13W (Excluding PoE output) |
| Dimensions | 137 x 98.7 x 30.2 mm (5.4 x 3.9 x 1.2") |
|---|---|
| Weight | 400 g (14.1 oz) |
| Features | Features Wireless Meshing Band Steering 802.11v BSS Transition Management 802.11r Fast Roaming 802.11k Radio Resource Management (RRM) Advanced Radio Management Passpoint (Hotspot 2.0) Captive Hotspot Portal Custom Branding Landing Page Voucher Authentication Payment-Based Authentication External Portal Server Support Password Authentication Guest Network Isolation Private Pre-Shared Key (PPSK) WiFi Speed Limiting Client Device Isolation WiFi Schedules RADIUS over TLS (RadSec) Dynamic RADIUS-assigned VLAN Hardware Networking Interface: (3) 2.5 GbE RJ45 ports Management: Ethernet Built-In Switch: (1) PoE+ input and (1) PoE output Channel Bandwidth: HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz) Performance Antenna Gain 5 GHz: 8 dBi 2.4 GHz: 4 dBi Max. TX Power 5 GHz: 24 dBm 2.4 GHz: 23 dBm Max. BSSIDs 8 per Radio |
|---|
| Date First Available | March 21, 2025 |
|---|
