Specifications: Charging Ports / Amps: (16) 2.4A
Input Connection Type: C14 inlet with 100-250V AC compatibility. Also accepts user-supplied country-specific AC cordsets
Voltage Compatibility (VAC): 100-250
Input Frequency: 50 / 60 Hz (auto-select)
Slot Dimensions (hwd / in.): 8.1 x 0.8 x 13.9
Certifications: Tested to EIA-310-E, UL60950, FCC & IEC Class B
NOM (Mexico): Tested to NOM (Mexico)
Approvals: RoHS
Specifications: Audio Specifications: 7.1 surround sound
Maximum Analog Resolutions: 1920 x 1200 or 1080p
Maximum Digital Resolutions: 3840 x 2160 @ 30 Hz
Supported Resolutions:
1024 x 768
1280 x 720 (High-definition 720p)
1920 x 1080 (High-definition 1080p)
1920 x 1200
2560 x 1440
2560 x 1600
3840 x 2160 (Ultra HD 4K)
Wide Screen Supported: Yes
Specifications: Resolution: 3840 x 2160 at 30Hz (Dual Display)
Resolution: 3840 x 2160 at 60Hz (Single Display)
Output: Requires 5V, 2A external power over Micro-B USB port
DisplayPort 1.2a compliant
Link Rate: HBR2/HBR/RBR
Bandwidth: 5.4Gbps max.
Support SST and MST (when both host and monitor support)
Support 7.1 sound channel; max. sampling size 192KHz
Rating: Temp 80°C, Voltage 30V
Conductor Resistance: At 20°C max 30AWG: 376.95 O/KM
Insulation Resistance: 10M -KM min at 20°C DC 500V (EIA-364-21)
Dielectric Strength: AC 500V/1 minute no breakdown (EIA-364-20)
Impedance: Pairs (differential mode) 100±50HMS
Attenuation (max.): 5.02dB@100~450MHz; 7.695dB@1GHz; 12.595dB@2GHz; 17.495dB@3GHz; 22.395dB@4GHz; 27.295dB@5GHz; 32.195dB@6GHz; 37.095dB@7GHz
Return...
Console Connectors: 1 x VGA (15 pin, High Density D-Sub) Female Input
Monitors Supported: Display Size: 19in
Brightness: 250 cd/m2
Color Depth: 8-bit, 16.7M colors
Contrast Ratio: 1000:1
IP Control: No
Maximum Analog Resolutions: 1280 x 1024
Maximum Number of Users : 1
MTBF: 50, 000 Hrs
Pixel Pitch Support: 0.264 x 0.264 mm
Supported Resolutions:
1024x768
1280x720 (High-definition 720p)
1280 x 1024
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
Genesys Logic - GL3523
Realtek - RTL8153
Eton Technology - EJ899T
Parade Technologies - PS176
ITE -IT6516
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Analog Resolutions: 1920 x 1200p @ 60Hz (VGA)
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p @ 30Hz (HDMI)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
macOS 10.11 to 10.14
Chrome OS
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 1
Video Ports: HDMI (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 1.4; HDCP 2.2
Supported Resolutions: 1280 x 720 (720p); 1920 x 1080 (1080p); 3840 x 2160 (4K)
Max Supported Video Resolution: 3480 x 2160 @ 60 Hz
Max. Distance (Between any 2 Units): 230 ft.
Maximum Distance with Booster: 400
Transmitter Video Input: HDMI
Transmitter - Number of Video Outputs: 1
Transmitter - Local Display Output: HDMI
Receiver/Transceiver Video Output: HDMI
Receiver - Number of Video Output: 1
Max Supported Color Depth: 36-bit Deep Color
HDR Support: Yes
3D Video Supported: Yes
Chroma Sub Sampling: 4:4:4
Maximum Signal Range (m): 70
HDCP Specification: 1.4; 2.2
Driver Required: No
Recommended...
Specifications: Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo ThinkPad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
Specifications: Audio: Yes
Chipset ID: NXP - PTN5100 / Pericom - PI3DPX1203
Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 4K (3840 x 2160) @ 60 Hz
Supported Resolutions:
1024 x 768
1280 x 720
1920 x 1080 @ 144hz
1920 x 1200
2560 x 1440
2560 x 1600
3840 x 2160 @ 60Hz
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Connector:
1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x Mini-DisplayPort (20 pin) Female Output
System and Cable Requirements:
Your USB-C device must support DisplayPort over USB-C (DP alt mode) to work with this adapter
This adapter outputs a single-mode Mini DisplayPort signal and will not work with additional video adapters such as Mini DisplayPort to HDMI, Mini DisplayPor...
Specifications: Interface: USB 3.0
Support Devices: IDE & SATA I/II/III, SSDs, Hard Drives, CD/DVD/Blu-ray Drives
Drive Size: 2.5" & 3.5" & 5.25"
LED Indicators: 1 x IDE; 1 x SATA; 1 x USB; 1 x Power
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10 (32 or 64 bit)
Mac OS X v10.6 and Up
Linux OS
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
Specifications: Connect A: USB 3.0 Type A Male
Connect B: RJ-45 (Gigabit Ethernet Port)
Type: USB 3.0 to Ethernet Converter
System Requirements:
Macintosh OS X 10.4 or above
Windows XP, Vista, 7 or above
Specifications: Maximum Analog Resolutions: 2048 x 1280p @ 60Hz
Maximum Data Transfer Rate: 5 Gbps (USB 3.0)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
PC Connectors: Video Input: (1) HDMI female, (1) DisplayPort female
Serial Control Port: (1) DB9 female
Link Port: (1) SFP cage
USB: (1) USB Type B female
Audio: (1) Line in, (1) Line out;
Local Video Output: (1) HDMI female, (1) DisplayPort female
Console Connectors: Video Output: (2) HDMI female
Serial Control Port: (1) DB9 male
Link Port: (1) SFP cage
USB 2.0: (4) USB Type A female
Audio: (1) Mic In, (1) Speaker Out
Video Resolution: Video
Output Cable Length: Up to 20 ft.
Input Cable Length: Up to 20 ft.
Resolution (Maximum): 4K 3840x2160 @ 30Hz
Input Equalization: Automatic
DDC: 5 volts p-p (TTL)
