System Requirements: Computer with DVI video and 3.5mm stereo audio connectors
Monitor with a DVI video connector
Monitor with a 3.5mm stereo audio connector; or, a set of speakers with a 3.5mm stereo audio connector
Feature: For use where DVI video and 3.5mm stereo audio signals need to be transmitted from a computer to multiple sets of monitors/speakers
Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
Power Supply: Input: 100-240V, 50/60Hz, 1.5A
Output: 12.6V, 3A
Specification: Cable Type: VGA
Display Style: Splitter
Color: Black
Connector A: HD15 (FEMALE)
Connector B: RJ45 (FEMALE) x 4
Feature: Splits a single VGA signal into 5 (1 local, 4 remote)
Increase the number of displays to up to 25 (1 local, 24 remote) by daisychaining up to six B132-004-2 units together
A B132-100-1 or B132-100-WP-1 remote receiver unit is required for each connected monitor
Extends a 1920 x 1440 (60Hz) signal up to 500 ft., or a 1024 x 768 (60Hz) signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6)
EDID copy feature ensures optimal display compatibility
The range and number of monitors can be further expanded by adding B132-110 repeater units
Connect up to 4 remote unit...
System Requirements: Computer with an HD15 port
VGA or SVGA monitor with HD15M cable
Specification: Rugged Metal Case
Feature: Connects two computers to one monitor or two monitors to one computer
Fully-shielded rugged metal case with front-panel push button switch
Does not require external power, software, or complicated set-up procedures
Power Supply: Input: 100-240V, 50/60Hz, 0.5A
Output: 5V, 2A
Specification: Connector A:3 x HD15 (FEMALE)
Connector B:2 x RJ45 (FEMALE)
Maximum Operating Distance:1000 ft
Number of Output Devices Supported:2
Number of Input Devices Supported:1
Twisted Pair Cable Standard:Category 6
Media Type Supported:Twisted Pair
Specification: Signal Type: Single-Link DVI-D
CE Approval: Yes
RoHS: Yes
Connectors Inputs: 1 x DVI-D, 1 x 3.5-mm stereo audio jack
Outputs: 2 x DVI-D, 2 x 3.5-mm stereo audio jacks
Indicators: 1 x Power/Video OK dual-color LED, 2 x Video Output LEDs
Resolution Support: 1080p (1920 x 1080), UXGA (1600 x 1200)/WUXGA (1920 x 1200)
Specification: Approvals: CE, RoHS
Distance: Cable lengths: 16.4 ft. (5 m) maximum
Connectors: Inputs: 1 x HDMI F; 1 x 3.5-mm audio
Outputs: 2 x HDMI F; 2 x 3.5-mm audio
This product works with:
-HDMI Female-DVI Male Adapter (FA795)
-HD View HDMI Extender (AC3010A)
Resolution Support: Full HD 1080p (1920 x 1080), VGA (640 x 480) maximum, SXGA (1280 x 1024), UXGA (1600 x 1200) maximum, WUXGA (1920 x 1200) maximum
