¥18,724
Consumption Sales Tax-Inclusive Price
Ships from Hong Kong.
Most customers receive within 10-17 days.
Meet Your Seller
Wenglor Proximity Switch HD03PA PNP New
- Wenglor Proximity Switch HD03PA PNP New
+
+
Overview
Specs
Reviews
Range 30 mm
Switching Hysteresis < 15 %
Light Source Infrared Light
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Opening Angle 12 °
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 40 mA
Switching Frequency 1500 Hz
Response Time 330 µs
Temperature Drift < 10 %
Temperature Range -25...60 °C
Switching Output Voltage Drop < 2,5 V
PNP Switching Output/Switching Current 200 mA
Residual Current Switching Output < 50 µA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Protection Class III
Housing Material CuZn, nickel-plated
Full Encapsulation yes
Degree of Protection IP67
Connection Cable, 4-wire, 2 m
MTTFd (EN ISO 13849-1) 2337,8 a
PNP NO/NC antivalent yes
Switching Hysteresis < 15 %
Light Source Infrared Light
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Opening Angle 12 °
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 40 mA
Switching Frequency 1500 Hz
Response Time 330 µs
Temperature Drift < 10 %
Temperature Range -25...60 °C
Switching Output Voltage Drop < 2,5 V
PNP Switching Output/Switching Current 200 mA
Residual Current Switching Output < 50 µA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Protection Class III
Housing Material CuZn, nickel-plated
Full Encapsulation yes
Degree of Protection IP67
Connection Cable, 4-wire, 2 m
MTTFd (EN ISO 13849-1) 2337,8 a
PNP NO/NC antivalent yes
