Wenglor Retro-Reflex Sensors LM89PA2 PNP New
- Wenglor Retro-Reflex Sensors LM89PA2 PNP New
+
+
Overview
Specs
Reviews
Wenglor Retro-Reflex Sensors LM89PA2 PNP New
Range 6500 mm
Reference Reflector/Reflector Foil RQ100BA
Switching Hysteresis < 15 %
Light Source Red Light
Polarization Filter yes
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Opening Angle 5 °
Two-Lens Optic yes
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 40 mA
Switching Frequency 1 kHz
Response Time 500 µs
Temperature Drift < 10 %
Temperature Range -10...60 °C
Switching Output Voltage Drop < 2,5 V
PNP Switching Output/Switching Current 200 mA
Residual Current Switching Output < 50 µA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Protection Class III
Setting Method Potentiometer
Housing Material Plastic
Full Encapsulation yes
Degree of Protection IP67
Connection M12 × 1; 4-pin
PNP NO/NC antivalent yes
Range 6500 mm
Reference Reflector/Reflector Foil RQ100BA
Switching Hysteresis < 15 %
Light Source Red Light
Polarization Filter yes
Service Life (T = +25 °C) 100000 h
Max. Ambient Light 10000 Lux
Opening Angle 5 °
Two-Lens Optic yes
Supply Voltage 10...30 V DC
Current Consumption (Ub = 24 V) < 40 mA
Switching Frequency 1 kHz
Response Time 500 µs
Temperature Drift < 10 %
Temperature Range -10...60 °C
Switching Output Voltage Drop < 2,5 V
PNP Switching Output/Switching Current 200 mA
Residual Current Switching Output < 50 µA
Short Circuit Protection yes
Reverse Polarity Protection yes
Overload Protection yes
Protection Class III
Setting Method Potentiometer
Housing Material Plastic
Full Encapsulation yes
Degree of Protection IP67
Connection M12 × 1; 4-pin
PNP NO/NC antivalent yes
