Resolution Support: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a);
1080p@100m
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60 Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30 Hz (4:4:4)
Video: Video
Max. Data Rate: 10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock: Up to 340 MHz
Compliance:
HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
System Requirements: Computer with an HD15 port
VGA or SVGA monitor with HD15M cable
Specification: Rugged Metal Case
Feature: Connects two computers to one monitor or two monitors to one computer
Fully-shielded rugged metal case with front-panel push button switch
Does not require external power, software, or complicated set-up procedures
Distance: 4K@60Hz Up to 230ft/70M via Cat6/7 cable
Resolution Support: Up to 3840x2160 @60Hz
Audio: PCM 7.1 / DTS-HD / Dolby Digital 5.1ch via HDMI and 3.5mm stereo audio from receiver
HDMI: Transmitting unit (TX):
1x 19-pin HDMI, Type A, Female, Input
1x 19-pin HDMI, Type A, Female, Loop out
Receiving unit (RX):
1x 19-pin HDMI, Type A, Female, Output
Specification: Approvals: CE, RoHS
Distance: Cable lengths: 16.4 ft. (5 m) maximum
Connectors: Inputs: 1 x HDMI F; 1 x 3.5-mm audio
Outputs: 2 x HDMI F; 2 x 3.5-mm audio
This product works with:
-HDMI Female-DVI Male Adapter (FA795)
-HD View HDMI Extender (AC3010A)
Resolution Support: Full HD 1080p (1920 x 1080), VGA (640 x 480) maximum, SXGA (1280 x 1024), UXGA (1600 x 1200) maximum, WUXGA (1920 x 1200) maximum
Specification: OVERVIEW
Display Style: Extender
Model Type: VGA
Cable Types: CAT5/CAT5E
PHYSICAL
Included Mounting Accessories: Yes
ENVIRONMENTAL
Operating Temperature Range: 0 to 40 C (32 to 104 F)
Storage Temperature Range: -20 to 60 C (-4 to 140 F)
Relative Humidity: 20 to 90%
CONNECTIONS
Connector A: HDMI (FEMALE) (X4)
Connector B: RJ45 (FEMALE) (X4)
Feature: Tripp Lite's B126-4X4 HDMI over Cat5/6 Matrix Splitter Switch and Transmitter Unit allows you to share high-definition video and audio from four HDMI-enabled digital video components (e.g., DVR, Cable Box, Blu-Ray, HD gaming consoles, etc.) to four different monitors. When used with Tripp Lite Active HDMI receivers, it can extend
Specification: Signal Type: Single-Link DVI-D
CE Approval: Yes
RoHS: Yes
Connectors Inputs: 1 x DVI-D, 1 x 3.5-mm stereo audio jack
Outputs: 2 x DVI-D, 2 x 3.5-mm stereo audio jacks
Indicators: 1 x Power/Video OK dual-color LED, 2 x Video Output LEDs
Resolution Support: 1080p (1920 x 1080), UXGA (1600 x 1200)/WUXGA (1920 x 1200)
Specification: Signal Inputs/Output
Input DDC Signal: 5 volts p-p (TTL)
Maximum Single Link Range: 4K x 2K
Output Video: HDMI 1.4 with full 3D and 4Kx2K@30Hz + HDCP
CEC - Pass through enabled
Operating Frequency
Vertical Frequency Range: 50/60Hz
Environment
Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
Video Bit Rate/Bandwidth: Video Amplifier Bandwidth: 2.97 Gbps
Resolution Support: Interlaced (50&60Hz): 480i, 576i, and 1080i
Progressive (50&60Hz): 480p, 576p, 720p, 1080p, and 4Kx2K
