MSI SPATIUM M470 PRO PCIe 4.0 NVMe M.2 2280 1TB PCI-Express 4.0 x4 3D NAND Internal Solid State Drive (SSD) - SM470PN1TB
- PCIe Gen4x4 interface and complies with the NVMe 1.3 standard
- Sequential Read speeds up to 6000MB/s and Write speeds up to 5000MB/s
- Up to 640 TBW
- Built-in data security and error-correction capabilities
- 1TB capacities in M.2 2280 form factor
- Suitable for both desktop and notebook
- 5-Year Warranty
+
+
Overview
Specs
Reviews (1)
Overview
The MSI SPATIUM M470 PRO is a 1TB internal solid state drive for consumer desktop and notebook systems. Its M.2 2280 form factor and PCIe 4.0 x4 interface provide a compact storage solution with NVMe 1.3 support.
Key Features
- 3D NAND memory components with a 1GB DRAM cache
- TRIM support for performance optimization, with OS support required
- SMART self-monitoring, analysis and reporting technology
- LDPC ECC algorithm and End to End Data Path Protection
- APST autonomous power state transition
- TCG OPAL2.0/Pyrite encryption and data security
Performance
The drive delivers maximum sequential read speeds of up to 6000 MBps and maximum sequential write speeds of up to 4500 MBps. 4KB random read and random write performance reach up to 950,000 IOPS each. Power consumption is PS3 20mW when idle and L1.2 2mW when active.
Design
The M.2 2280 form factor measures 80mm in width, 22mm in depth and 2.15mm in height. The drive is supplied without a heatsink.
Connectivity & Compatibility
The drive uses a PCI-Express 4.0 x4 interface and NVMe 1.3 protocol. It is suitable for compatible consumer desktop and notebook systems with an M.2 2280 drive slot.
Reliability & Durability
The drive is rated for up to 320TB written and up to 1,700,000 hours MTBF. Operating temperature is 0°C to +70°C, while storage temperature is -40°C to +85°C. End to End Data Path Protection, LDPC ECC and TCG OPAL2.0/Pyrite encryption provide supported data protection and security features.
Specifications
- Brand: MSI
- Model: SPATIUM M470 PRO PCIe 4.0 NVMe M.2
- Part Number: SM470PN1TB
- Device Type: Internal Solid State Drive (SSD)
- Used For: Consumer
- Capacity: 1TB
- Memory Components: 3D NAND
- Form Factor: M.2 2280
- Interface: PCI-Express 4.0 x4
- Protocol: NVMe 1.3
- Controller: PHISON E27T
- Cache: 1GB DRAM
- Encryption: TCG OPAL2.0/Pyrite
- Max Sequential Read: Up to 6000 MBps
- Max Sequential Write: Up to 4500 MBps
- 4KB Random Read: Up to 950,000 IOPS
- 4KB Random Write: Up to 950,000 IOPS
- Terabytes Written (TBW): 320TB
- MTBF: Up to 1,700,000 Hours
- HeatSink: without HeatSink
- Idle Power Consumption: PS3 20mW
- Active Power Consumption: L1.2 2mW
- Operating Temperature: 0°C ~ +70°C
- Storage Temperature: -40°C ~ +85°C
- Dimensions: 80mm width x 22mm depth x 2.15mm height
