10.1 Inch Backlit TFT LED Embedded Industrial Panel PC, Resistive Touch Screen, Celeron J1900, HUNSN PW12, 1024 x 600, VGA, 4 x USB, LAN, 3 x COM, Barebone, NO RAM, NO Storage, NO System
- 10.1 inch tft lcd led backlight screen industrial grade panel, imported resistive touch screen, typical 1024 x 600 resolution, powered by celeron quad core j1900 processor, applicable to a wide range of industrial applications, 7 x 24 hours of stable work
- Please note, this is a barebone only. A system memory, a storage drive and an operating system are needed to complete this system
- Aluminum alloy fanless passive cooling design, silent solution thats ultra energy-efficient
- HUNSN PW12 designed with 12v dc, vga, 3 x com, usb3.0, 3 x usb2.0, lan, audio-in&out, industrial aesthetic design and reasonable interface layout, support automatically power on after power failure, with mounting embedded buckle kits
- Size at 270 x 192 x 47mm, 3.0kgs, 12v power supply, with power cord, make sure to use a big brand memory and ssd/hdd with quality assurance, very powerful fanless all in one panel touch pc
+
+
Overview
Specs
Reviews
Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this system
Model Number: HUNSN PW12
Panel: 10.1 Inch TFT LED screen industrial grade panel
CPU: Intel® Celeron® Processor J1900 (2M Cache, up to 2.42 GHz)
Memory: 1 x SODIMM DDR3L 1333, max. to 8GB RAM
Storage: 1 x mSATA SSD
I/O: 12V DC, VGA, 3 x COM, USB3.0, 3 x USB2.0, LAN, AUDIO-IN&OUT
Expansion: Mini PCIE slot for WiFi/4G, with sim slot
Cooling System: Aluminum alloy, fanless
Dimension: 270 x 192 x 47mm
Weight: 3.0kgs
Opening Hole: 227 x 183mm
Resolution: 1024 x 600
Perspective: 45(L), 45(R), 15(T), 35(B)
Brightness: 200cd/m2
Contrast: 400
Backlight Life: 10,000 hours (min.)
Touch Screen: Resistive touch screen
Durability (Touch Count): 5 million times
Installation: Embedded recommended/Wallmounted/Desktop/Cantilevered etc
Operating Temperature: 0 ~ 50°C with SSD, 0 ~ 40°C with HDD
Storage Temperature: -20 ~ 60
Operating Humidity: 10% ~ 95% @ 40 without condensation
EMC/Safety: CCC
Power Supply: DC100-240V AC/50-60Hz, 12V
Packing List: HUNSN PW12 Panel PC, Power Supply, Power Cord, Embedded Buckle Kits, Warranty Card
System Support: Windows 10/11, Linux Ubuntu etc
Model Number: HUNSN PW12
Panel: 10.1 Inch TFT LED screen industrial grade panel
CPU: Intel® Celeron® Processor J1900 (2M Cache, up to 2.42 GHz)
Memory: 1 x SODIMM DDR3L 1333, max. to 8GB RAM
Storage: 1 x mSATA SSD
I/O: 12V DC, VGA, 3 x COM, USB3.0, 3 x USB2.0, LAN, AUDIO-IN&OUT
Expansion: Mini PCIE slot for WiFi/4G, with sim slot
Cooling System: Aluminum alloy, fanless
Dimension: 270 x 192 x 47mm
Weight: 3.0kgs
Opening Hole: 227 x 183mm
Resolution: 1024 x 600
Perspective: 45(L), 45(R), 15(T), 35(B)
Brightness: 200cd/m2
Contrast: 400
Backlight Life: 10,000 hours (min.)
Touch Screen: Resistive touch screen
Durability (Touch Count): 5 million times
Installation: Embedded recommended/Wallmounted/Desktop/Cantilevered etc
Operating Temperature: 0 ~ 50°C with SSD, 0 ~ 40°C with HDD
Storage Temperature: -20 ~ 60
Operating Humidity: 10% ~ 95% @ 40 without condensation
EMC/Safety: CCC
Power Supply: DC100-240V AC/50-60Hz, 12V
Packing List: HUNSN PW12 Panel PC, Power Supply, Power Cord, Embedded Buckle Kits, Warranty Card
System Support: Windows 10/11, Linux Ubuntu etc
