X79M Motherboard LGA 2011 CPU Xeon E5 Support ECC REG DDR3 128GB M.2 NVME NGFF SATA3.0 USB2.0 X79 Server Mainboard
- X79M Motherboard LGA 2011 CPU Xeon E5 Support ECC REG DDR3 128GB M.2 NVME NGFF SATA3.0 USB2.0 X79 Server Mainboard
+
+
Overview
Specs
Reviews
Specification:
Model: X79M
Chipset: Intel C602/X79
CPU Type: Intel LGA2011 Xeon E5 Series V1/C2/V2
Memory Slot: 4*DDR3
Memory Channel: Dual Channel
Maximum Memory Capacity: 128GB (32GB Each)
Memory Frequency: 1866/1600/1333/1066MHz
Memory Type Supported: Non-ECC/REG&ECC/REG
SATA Interface: SATA 3.0 x1 SATA 2.0 x3
USB Interface: USB 2.0 x10 (Including Expansion)
PCI-E Slot: 1*PCI-E 3.0 x16 1*PCI-E x1
M. 2
Interface: M. 2 NVME/NGFF (By Jumper Switch)
Integrated Graphics Card: No
Audio Chip: ALC662 5.1 Channel
Ethernet: 10/100/1000M
Internal I/O Ports: 1*CPU Fan Connector, 2*Chassis Fan Connector
Form Factor: M-ATX (242mmx190mm)
Memory Installation Tips: Memory slot yellow is the main slot, and red is the sub slot, which must be inserted into the main slot first.
Note:
1. The color of the bottom plate of the slot may vary from batch to batch, but it will not affect the use of the product. The product is constantly optimized and upgraded.
2. Please allow 1-3mm differs due to manual measurement.
3. Due to different lighting and shooting conditions, the color of the picture may differ slightly from the actual product. Please refer to the actual product.
4. This planform needs powerful power supply. Please make sure your power supply can enough to supports this planform, recommend power above 500W.
5. The motherboard did not included CMOS battery, because the transportation rules prohibit battery.
Model: X79M
Chipset: Intel C602/X79
CPU Type: Intel LGA2011 Xeon E5 Series V1/C2/V2
Memory Slot: 4*DDR3
Memory Channel: Dual Channel
Maximum Memory Capacity: 128GB (32GB Each)
Memory Frequency: 1866/1600/1333/1066MHz
Memory Type Supported: Non-ECC/REG&ECC/REG
SATA Interface: SATA 3.0 x1 SATA 2.0 x3
USB Interface: USB 2.0 x10 (Including Expansion)
PCI-E Slot: 1*PCI-E 3.0 x16 1*PCI-E x1
M. 2
Interface: M. 2 NVME/NGFF (By Jumper Switch)
Integrated Graphics Card: No
Audio Chip: ALC662 5.1 Channel
Ethernet: 10/100/1000M
Internal I/O Ports: 1*CPU Fan Connector, 2*Chassis Fan Connector
Form Factor: M-ATX (242mmx190mm)
Memory Installation Tips: Memory slot yellow is the main slot, and red is the sub slot, which must be inserted into the main slot first.
Note:
1. The color of the bottom plate of the slot may vary from batch to batch, but it will not affect the use of the product. The product is constantly optimized and upgraded.
2. Please allow 1-3mm differs due to manual measurement.
3. Due to different lighting and shooting conditions, the color of the picture may differ slightly from the actual product. Please refer to the actual product.
4. This planform needs powerful power supply. Please make sure your power supply can enough to supports this planform, recommend power above 500W.
5. The motherboard did not included CMOS battery, because the transportation rules prohibit battery.
