Question 1

I want to put a GeForce GTX 750 Ti in this case. Will it fit?

Accepted Answer

The GTX 750ti is too big of a GPU to fit in this case. You will need a case that has at least 2 full height PCI slots as that GPU is a dual slot full height card.

Question 2

I get that It does not come with one, but can i still put a disk drive into it and have it function properly?

Accepted Answer

I did not put a CD drive into it, but the manual has some details about how to do just that.  It definitely supports CD drives, but ONLY SLOT LOADING ONES.

I can't include links, but you can just google "slot loading cd drive" and you'll see what I'm talking about.

Question 3

Does this case come with the disk drive?

Accepted Answer

No, this is just the case. A disk drive would need to be purchased separately.

Question 4

Will a micro-ATX board mount in this case?

Accepted Answer

No.  The case is too small for a micro ATX board.

Question 5

Hi Just wondering if anyone has used the 4in1 bracket to mount a 3.5HDD and whether a stock i3 4130 cpu cooler would still fit or if low profile is required?

Thanks

Accepted Answer

Yes the bracket will work and so will the cooler

Question 6

What is the benefit of the second expansion slot (the horizontal one). I'm looking for a case that will handle 2x HVR-2250's. Can the second HVR-2250 fit horizontally? If so, what motherboards support this riser-style configuration?

Accepted Answer

The second expansion slot is used for: 1) additional video connections, like the tuner card you reference (which I have as well) has an additional component and s-video connections on a small panel that connects to the main PCI board. 2) a place for your wifi antenna connections.  There are likely other possibilities.  Note that mini-ITX boards like the ML06 fits do not usually have more than one PCI Express slot.

Question 7

Hi, will the gtx 650 low profile fit without fouling the psu?

Accepted Answer

I have a wireless card in the PCIe slot and there's not much clearance.  I doubt any card with a fan on it would work.

Question 8

Does this case have an eject button for the optical drive?

Accepted Answer

No it doesn't

Brand	SILVERSTONE
Series	Milo Series
Model	ML06B

Color	Black
Case Material	7mm aluminum front panel, 0.8mm steel body
Power Supply	1 x Optional standard SFX
Motherboard Compatibility	Mini ITX

External 3.5" Drive Bays	9.5mm/12.7mm slim slot-loading optical drive x 1 (replaceable with 3.5” HDD x 1 or 2.5” HDD x 2 or 120mm fan x 1)
Internal 2.5" Drive Bays	4
Expansion Slots	1

Front USB Ports	USB 3.0 x 2
Front Audio Ports	Audio x 1, MIC x 1

80mm Fans	Right Side: 2 x 80mm fan slot
120mm Fans	Top: 120mm fan slot / oversized PSU vents

Meet Your Seller

SILVERSTONE MILO Series ML06B Steel Body Mini-ITX Media Center/ HTPC Computer Case with Aluminum Front Panel

Learn more about the Silverstone ML06B

Customer Reviews of the Silverstone ML06B

Warranty & Returns

Warranty, Returns, And Additional Information

Return Policies*

Manufacturer Contact Info

Dimensions & Weight
Height	3.90"
Width	13.78"
Depth	8.07"
Weight	5.29 lbs.

Item#: 9SIAD6HKHC1303
