Brand | PNY |
---|---|
Series | XLR8 |
Model | VCGGTX1080T11PB-OC2 |
Interface | PCI Express 3.0 x16 |
---|
Chipset Manufacturer | NVIDIA |
---|---|
GPU Series | NVIDIA GeForce GTX 10 Series |
GPU | GeForce GTX 1080 Ti |
Core Clock | 1506 MHz |
Boost Clock | 1620 MHz |
CUDA Cores | 3584 Cores |
Effective Memory Clock | 11 Gbps |
---|---|
Memory Size | 11GB |
Memory Interface | 352-Bit |
Memory Type | GDDR5X |
DirectX | DirectX 12 |
---|
Multi-Monitor Support | Yes |
---|---|
HDMI | 1 x HDMI 2.0b |
DisplayPort | 3 x DisplayPort 1.4 |
Max Resolution | 7680 x 4320 |
---|---|
SLI Support | SLI HB Bridge Supported |
Virtual Reality Ready | Yes |
Cooler | Single Fan |
Thermal Design Power | 250W |
System Requirements | TDP: 250W PCI Express-compliant motherboard with one dual-width x16 graphics slot One 6-pin, One 8-pin PCI Express supplementary power connectors Minimum 600W or greater system power supply* 300MB of available hard-disk space 8GB system memory (16GB or higher recommended) Windows 7-10, Linux, FreeBSDx86 Internet connection** *Recommendation is made based on PC configured with an Intel Core i7 3.2 GHz processor. Pre-built system may require less power depending on system configuration. **Graphics Card driver is not included in the box; GeForce Experience will download the latest GeForce driver from the Internet after install. |
Power Connector | 1 x 6-Pin + 1 x 8-Pin |
Features | Simultaneous Multi-Projection VR Ready NVIDIA Ansel Support NVIDIA SLI w/ HB Bridge Support NVIDIA G-SYNC NVIDIA GameStream NVIDIA GPU Boost 3.0 Microsoft DirectX 12 Support Vulkan API Support Open GL 4.5 Support PCI Express 3.0 Max Digital Resolution - 7680x4320@60Hz* Display Connectors (3x) DP 1.4 (1x) HDMI 2.0b *7680x4320 @60Hz RGB 8-bit with dual DisplayPort connectors or 7680x4320 @60Hz YUV420 8-bit with DisplayPort 1.3 connector. |
---|
Max GPU Length | 267 mm |
---|---|
Card Dimensions (L x H) | 10.51" x 4.41" |
Slot Width | 2 Slots |
Package Contents | GeForce GTX 1080 Ti Gaming Overclocked Blower Edition Graphics Card Quick Installation Guide One PCIe 8-pin power adapter DisplayPort to DVI Adapter |
---|
First Listed on Newegg | July 26, 2021 |
---|
Warranty Notice:
This product does not include manufacturer warranty when purchased or used outside of its designated sales region. By purchasing internationally, you acknowledge that warranty support from the manufacturer will not be available.
