| Wireless Standard | IEEE 802.1Q |
|---|
| Network Protocols | IPSec Site-to-Site, IPSec Client-to-Site, OpenVPN Client-to-Site, WireGuard |
|---|
| Device Management | NETGEAR Insight Remote/Cloud Management: Instant discovery, configuration, and management of your network and
Pro Router
QoS (Smart Queue Management): Mitigates upload/download latency per WAN port.
Insight Cloud Management Features:
Logging:Accepted Packets, Dropped Packets Statistics, System, Source MAC filter, Session Limit, Bandwidth Limit, IPsec VPN
Log Delivery: Insight logging
Troubleshoot: Diagnostics Ping, DNS Lookup, Trace Route, Speed test
Maintenance: Save/Restore Configuration, Restore to Factory Defaults, Firmware Upgrades, Display and Monitor Statistics |
|---|
| Security | Firewall Functions:
Firewall Traffic Rules/Scheduling, Port Forwarding, Port Triggering, Stateful Packet Inspection (SPI), Port/Service Blocking, Denial-of-service (DoS), Prevention, Stealth Mode, Block TCP Flood, Block UDP Flood, Respond To Ping on Internet Port
VoIP SIP ALG: Yes |
|---|
| WAN Ports | 10G/Multi-Gigabit throughput with 1x2.5G WAN
1x10G/Multi-Gigabit WAN/LAN configurable 3x2.5G LAN |
|---|
| LAN Ports | 1x10G SFP+ |
|---|
| Throughput | Maximum VPN Throughput: Site-to-Site 4.42 Gbps using 2.5G WAN; 8.92 Gbps using 10G WAN; Client-to-Site 500 Mbps
WAN-to-LAN Throughput:
When using WAN2 port - 10Gbps max WAN with 17.5Gbps max LAN
When using WAN1 port only - 2.5Gbps max WAN with 27.5Gbps max LAN
LAN-to-WAN Throughput:
For 2.5G WAN port, LAN-to-WAN throughput is 2.4Gbps
For 10G WAN port, LAN-to-WAN throughput is 9.4Gbps |
|---|
| VPN support | Protocol : PSec Site-to-Site, IPSec Client-to-Site, OpenVPN Client-to-Site, WireGuard
IPsec Encryption/Authentication: 3DES, AES (128, 192, 256 bit)/SHA-1, SHA-2 (256 bit), MD5
Key Exchange: IKEv1, IKEv2, Pre-shared Key
Access Modes: Remote access via Insight Remote Cloud Management |
|---|
| Power Supply | AC 100-240V, 50/60Hz, 1.3A |
|---|
| Memory | 2GB DDR4/4GB eMMC |
|---|
| Temperature | Operating Temperature: 0° - 40°C (32°-104° F)
Storage Temperature: -20° - 70° C (-4° - 158° F) |
|---|
| Humidity | Operating humidity 90% maximum relative humidity, non-condensing
Storage humidity 95% maximum relative humidity, non-condensing |
|---|
