Specification: Signal Inputs/Output
Input DDC Signal: 5 volts p-p (TTL)
Maximum Single Link Range: 4K x 2K@30Hz
Output Video: HDMI 1.4 with full HD 1080p, 1920x1200, 720p, 3D and 4Kx2K + HDCP
CEC - Pass through enabled
Operating Frequency
Vertical Frequency Range: 50/60Hz
Environment
Operating Temperature: 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature: -20°C ~ 60°C / -4°F ~ 140°F
Video Bit Rate/Bandwidth: Video Amplifier Bandwidth: 2.97 Gbps
Resolution Support: Interlaced (50&60Hz): 480i, 576i, and 1080i
Progressive (50&60Hz): 480p, 576p, 720p, 1080p, and 4Kx2K@30Hz
Converter Type: Async RS232 to RS422/485 Interface Converter
Feature: Transmit data up to 115 kbps or at distancesup to 4000 ft.
Operates in point to point or multipoint applications
Operates 2-wire half-duplex or 4-wire half- or full-duplex.
async (data leads) only.
Up to 32 RS485 devices can be attached to create a large multi-drop network
The RS485 driver is automatically enabled during each spacing state on the RS232 side.
Distance: Max Distance: 70m (230 ft.)
Maximum 1080p Distance: 70m (230 ft.)
Maximum 4K Distance: 35m (115 ft.)
Resolution Support: 4K x 2K (Ultra HD) @ 30 Hz
2560 x 1600 @ 60 Hz
1920 x 1200
1920 x 1080 (1080p)
1280 x 720 (720p)
Power Consumption: 64.8W
Power Supply: Center Tip Polarity: Positive
Input Current: 1.5A
Input Voltage: 100 ~ 240 AC
Output Current: 2.7A
Output Voltage: 24 DC
Plug Type: 4-pin DIN
Power Source: AC Adapter Included
System Requirements: Computer with DVI video and 3.5mm stereo audio connectors
Monitor with a DVI video connector
Monitor with a 3.5mm stereo audio connector; or, a set of speakers with a 3.5mm stereo audio connector
Feature: For use where DVI video and 3.5mm stereo audio signals need to be transmitted from a computer to multiple sets of monitors/speakers
Feature: Cleans up Home Theater installations by hiding HDMI Cables
Simple Feed-Through design
Standard electrical outlet size
HDCP Compliant
Use with wall-mount Flat Panel Displays where cables need to be hidden
