| Specifications | Compliant with HDMI 2.0a and DisplayPort 1.2a specifications
Compliant with HDCP 1.4 and 2.2
Supports xvYCC, x.v.Color and Deep Color
Supports 4K2K@60Hz 4:4:4 8bits
Supports 8-bit, 10-bit, and 12-bit Deep Color
Video bandwidth: 18Gbps (single-link 600MHz)
Resolution support: 720p/1080i/1080p/2160p
Resolution up to 3840 x 2160 @60Hz (4:4:4 8bit)
Supports audio extraction via 3.5mm Stereo jack or Toslink 5.1ch (only one audio output can be used at a time)
Supported audio formats: HDMI: PCM 2 / 5.1 / 7.1, Dolby 5.1 / 7.1, DTS 5.1 / 7.1 Toslink: PCM2.0 & Digital 5.0 Stereo 3.5mm: PCM2.0
ESD protection: +/- 15kV Air / +/- 8kV Contact
Metal housing with wall mount design
Supports transmission distance (cable length): 4K @60Hz: Up to 10m (5m/In; 5m/Out) 1080p & 4K@30Hz: Up to 15m (5m/In; 10m/Out)
EDID mode indicator LED: Red: 3840x2160@60Hz Green: 4096x2160@60Hz Blue: 1080p@60Hz Yellow: EDID learning, support 1920x1080@144Hz, 120Hz, 100Hz
Housing material: Metal
Connector: 1 x 19-Pin, HDMI, Type A, Female, Input 1 x 20-Pin, DisplayPort, Female, Output 1 x S/PDIF (Toslink), Audio, Output 1 x 3.5mm, phone jack, Stereo audio, Output 1 x 5-Pin, Micro USB, Female, Power Input 1 x Push button, EDID selection
Power adapter: Input: 100-240VAC, 50/60 Hz Output: DC5V/2A UL listed: 135856/Level: VI
Environmental conditions: Operating temperature: 32 to 104 degrees F Storage temperature: -4 to 140 degrees F Relative humidity: 20 to 90% RH (non-condensing)
Certifications/Standards: FCC, CE, RoHS
TAA compliant |
|---|
