| WiFi Generation | Wi-Fi 7 |
|---|
| Wireless Standard | IEEE 802.11a / IEEE 802.11ac / IEEE 802.11ax / IEEE 802.11b / IEEE 802.11be / IEEE 802.11g / IEEE 802.11n |
|---|
| Security | WiFi Encryption : WPA/WPA2/WPA3 Personal WPA/WPA2/WPA3 Enterprise Open System & OWE WPS Let's Encrypt DNS-over-TLS SSH Security Scan Firewall - Maximum Firewall Keyword Filter : 64 - Maximum Firewall Network Service Filter : 32 - Maximum Firewall URL Filter : 64 |
|---|
| WAN Ports | 1 x 2.5G + 1 x 10G |
|---|
| LAN Ports | 1 x 10/100/1000M / 1 x 10G / 3 x 2.5G |
|---|
| LEDs | 1 x WAN(Internet) 1 x 10G LAN 1 x 1G/2.5G LAN 1 x 6GHz-2 1 x 6GHz-1 1 x 5GHz 1 x 2.4GHz 1 x Power |
|---|
| Buttons | WPS Button, Reset Button, Power Switch, LED control Button |
|---|
| Wireless Data Rates | 2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps 5GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbp 6G-1Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbp 6G-2Hz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbp |
|---|
| Frequency Band | 2.4 GHz / 5 GHz / 6 GHz / 6 GHz |
|---|
| Antenna | 8 x External antenna |
|---|
| Operation Mode | Access Point Mode / AiMesh Node Mode / Media Bridge Mode / Wireless Repeater Mode / Wireless Router Mode |
|---|
| Interface | 1 x USB 3.2 Gen1 1 x USB 2.0 |
|---|
| VPN support | Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion |
|---|
| Power Supply | AC Input: 110V~240V (50~60Hz) DC Output: 19.5 V with max. 3.33 A current |
|---|
| Processor | 2.6GHz quad-core processor |
|---|
| Memory | 256 MB Flash and 2 GB RAM |
|---|
| Dimensions | 14.96" x 14.96" x 5.51" |
|---|
| Weight | 4.41 lbs. |
|---|
