Specifications: Mount both PCIe (NVMe) and SATA based M.2 SSDs inside your computer using this PCI Express adapter card
3 Port M.2 SSD (NGFF) Adapter Card / 1 x PCIe (NVMe) M.2 / 2 x SATA III M.2 / PCIe 3.0
PCI Express 3.0 M.2 NGFF Card
Easily expand the storage and improve the overall performance of your desktop or server
Supports PCI Express 3.0 (x4) ideal for a high-performance M.2 PCIe SSD (NVMe)
OS independent with no drivers required for a fast hassle-free set up
Includes a low-profile bracket
Connector A: Connector Type(s): 1 x PCI Express x4 Male
Connector B: Internal Ports: 3 x M.2 (NGFF, B-Key) Receptacle / 2 x SATA (7 pin; Data) Plug
Specifications: Maximum Analog Resolutions: 2048 x 1280p @ 60Hz
Maximum Data Transfer Rate: 5 Gbps (USB 3.0)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Specifications: Maximum Digital Resolutions: 3840 x 2160 @ 60Hz
Supported Resolutions:
3840 x 2160 @ 60Hz
2560 x 1600
2048 x 1280
1920 x 1200
1920 x 1080
1280 x 720
1680 x 1050
1600 x 900
1440 x 900
1360 x 768
1280 x 800
1280 x 768
Wide Screen Supported:Yes
Humidity: 0~90% RH
Operating Temperature: 0 C to 40 degree C
Storage Temperature: -20C to 70 degree C
Output Connector: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x DisplayPort (20 pin) Female Output
Specifications: Interface: USB 3.0, RJ45 (Gigabit Ethernet)
Ports: 3
USB-C Device Port (s): USB Power Delivery
USB-C Host Connection: Yes
Auto MDIX: Yes
Auto-Negotiation: Yes
Compatible Networks: 10/100/1000 Mbps
Flow Control: Full duplex flow control
Full Duplex Support: Yes
Jumbo Frame Support: 9K max.
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Power Delivery Support: 60W
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows XP, Vista, 7, 8, 8.1, 10
Windows Server 2003, 2008 R2, 2012, 2016
Mac OS X 10.7 to 10.12 VLAN tagging is currently not supported in Mac OS
Linux Kernel 2.6.25 to 4.4.x LTS Versions only
Specifications: Audio Specifications: HDMI output - 7.1 surround sound; DVI output - 2-channel stereo audio
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 × 2160
Maximum Power Delivery Support: None
Supported Resolutions: HDMI output: 3840 x 2160 (@ 30 Hz), 2560 x 1600, 2048 x 1280 (@ 60 Hz), 1920 x 1200, 1920 x 1080, 1280 x 720; VGA and DVI output: 1920 x 1200 (@ 60 Hz), 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Output Connector: 1 x HDMI (19 pin) Female Output
1 x DVI-I (29 pin) Female Output
1 x VGA (15 pin, High Density D-Sub) Female Output
Specifications: Audio Specifications: HDMI and mDP output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160
Supported Resolutions:
HDMI and mDP output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported
Humidity: 40%-50%RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
Specifications: The USBPLATE4 4 port USB 2.0 slot plate adapter converts the USB pins on your motherboard into four USB-A female ports, enabling you to add USB connections to the back of your PC.
Backed by Lifetime Warranty, the USBPLATE4 is designed and constructed for maximum durability, to ensure dependable performance.
Please Note: Check your motherboard’s manual for the USB pinout diagram. The USBPLATE wiring scheme is: Red=Power, Green=Signal, White=Signal, Black=Ground
Connector A: 2 x IDC (10 pin, Motherboard Header) Female
Specifications: 1 - Connector A: USB-C (24 pin) USB Power Delivery only
1 - Connector B: USB-C (24 pin) USB Power Delivery only & 3.5 mm Audio
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Storage Temperature: -10°C to 70°C (14°F to 158°F)
Humidity: 10%-85% RH
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
VIA/VLI - VL102
VIA/VLI - VL817
Parade - PS8338B
Parade - PS176
Analogix - ANX9833
ALCOR MICRO - AU84612
Realtek - RTL8153
Fast-Charge Port(s): Yes
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Audio Specifications: The HDMI port supports audio output
Compatible Networks: 10/100/1000 Mbps
Auto MDIX: Yes
Full Duplex Support: Yes
Maximum Resolutions:
1920 x 1200p @ 60Hz (VGA)
3840 x 2160p (HDMI) @ 30Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p
Maximum Data Transfer Rate : 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
UASP Support: Yes
Powe...
Specifications: Note: Some legacy DVI monitors may be limited to a resolution of 1920x1200 when used with this adapter
Maximum Digital Resolutions: 2560 x 1600
Supported Resolutions: 1024 x 768, 1280 x 720 (High-definition 720p), 1920 x 1080 (High-definition 1080p), 1920 x 1200, 2560 x 1440, 2560 x 1600
Connector A: 1 x USB-C (24 pin) Male Input
Humidity: 5 - 90% RH (Non-condensing)
Operating Temperature: 0 to 70 degree C
Storage Temperature: -10 to 80 degree C
Specifications: Connector on First End: 1 x Mini-phone Female Stereo Audio
Connector on Second End: 1 x Mini-phone Female Stereo Audio
Material: PVC
Plating: Gold-Plated Connectors
