Specifications: 4K Support: Yes
Bus Type: USB-C
Displays Supported: 1
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0), 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
Maximum Power Delivery Support: 60 W
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
Mac OS 10.9 to 10.12
Chrome OS
Specifications: Ports: 1
Input Current: 1.5A
Input Voltage: 100 - 240 AC
Output Current: 3A
Output Voltage:
5V DC
9V DC
12V DC
15V DC
20V DC
Power Consumption (In Watts): 60W
Power Delivery: 60W
Connector A: 1 x NEMA 1-15 Power (North America) Male
Specifications: Long-Distance Data Transfer to 1 Device—Up to 164 ft. (50 m) from the Source
Send data to a USB 2.0 device located up to 164 ft. from the source
USB signals travel over a single user-supplied Cat5/Cat6 cable
Includes transmitter with built-in USB-A cable and a 1-port receiver
Supports data transfer rates up to 480 Mbps
Greater Distance over Cat5/Cat6 Cable Provides Greater Flexibility
Cat5/Cat6 cabling exceeds the 16 ft. distance limitation of USB cables
Allows connection to devices that lack network connectivity in areas beyond the reach of standard USB cables
Makes connections in areas without network availability
Allows source to be in a secure location, separate from peripherals
Cat5/Cat6 cabling is cost-effective and readily available
For best resul...
Specifications: Output Signal: VGA
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: PC resolutions up to 1920 x 1200 @ 60 Hz
Connector Type(s): 1 x USB Micro-B (5 pin) Female
Power Source: USB-Powered
Humidity: 40 - 85%RH
Operating Temperature: 0 to 60 degree C (32 to 140 degree F)
Storage Temperature: -10 to 70 degree C (14 to 158 degree F)
Specifications: Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 3840 x 2160 (Ultra HD 4K) @ 60hz
Supported Resolutions: 1024 x 768, 1280 x 720, 1920 x 1080, 1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
Connector Type(s): 1 x USB Type-C (24 pin) USB 3.0 Female
System and Cable Requirements: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
Humidity: 25% to 85% RH Non-Condensing
Operating Temperature: 5 to 35 degree C (41 to 95 degree F)
Storage Temperature: 5 to 35 degree C (41 to 95 degree F)
Specifications: Audio: Yes
Chipset ID: MCT - T6-688L
Memory: DDR 4Gb
Output Signal: DisplayPort
Audio Specifications: 2-channel stereo
General Specifications:
This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Maximum Digital Resolutions: 4K x 2K @ 30Hz
Supported Resolutions Widescreen(16/32 bit):
3840×2160, 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720
Standard(16/32 bit):
1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640X480
Wide Screen Supported: Yes
Connector(s)
Connector A: 1 - USB Type-A (9 pin) USB 3.0 Male Input
Connector B: 1 - DisplayPor...
Specifications: Connect a PCIe M.2 SSD (NVMe or AHCI) to your computer through PCI Express for ultra-fast data access
x4 PCI Express to M.2 PCIe SSD Adapter
M.2 NGFF SSD (NVMe or AHCI) Adapter Card
x4 PCIe expansion card
Expansion bay adapter supports M key M.2 NGFF PCIe SSD
Add a high speed 4-lane M.2 NGFF SSD such as Samsung 950 Pro or Samsung SM 951 to your PC
Wide compatibility with M.2 SSDs (NVMe and AHCI): 110mm, 80mm, 60mm and 42mm
OS independent for fast and easy set-up
Specifications: DisplayPort Compliant: DisplayPort V1.2
DVI Compliant: DVI 1.0
Content Protection: DPCP & HDCP Input: DisplayPort Male
Output: DVI-D Female
TMDS Clock Rate: 225MHz max. Bandwidth: 6.75 Gbps
Video Resolution: 1080p @60Hz, 1920x1200 (reduced blanking)
3D Video Support: No
Audio Support: No AMD Eyefinity: up to 6 displays (depending on graphic card) Driver: Plug and Play, No Software to Install Power by: DisplayPort source
Specifications: Output Signal: VGA
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: PC resolutions up to 1920 x 1200 @ 60 Hz
Connector Type(s): 1 x USB Micro-B (5 pin) Female
Power Source: USB-Powered
Humidity: 40 - 85%RH
Operating Temperature: 0 to 60 degree C (32 to 140 degree F)
Storage Temperature: -10 to 70 degree C (14 to 158 degree F)
Specifications: Converter Type: Passive
Output Signal: DVI-D (DVI Digital)
Maximum Digital Resolutions: 1920 x 1200 / 1080p
System and Cable Requirements: DP++ port (DisplayPort ++) required on video card or video source (DVI and HDMI pass-through must be supported)
Specifications: USB-C to HDMI Adapter
IOGEAR's USB Type-C to HDMI adapter is the ideal hardware solution to convert a USB-C connection to an HDMI video output. This gives you the ability to connect your USB-C-based device like the Apple MacBook, Google Chromebook Pixel and the Nokia N1 Tablet to any HDMI based display, projector or HDTV.
USB-C - The Next Break Through in Connectivity
USB-C is the latest advancement in the consumer electronics industry for device connectivity. Supporting a universal connectivity standard, USB-C unites all of your core functions into one powerful port. Thanks to its versatile design, compact footprint and unparalleled performance, USB-C connections are featured on next generation ultra-portable devices like the Apple MacBook, Google Chrome...
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID:
Genesys Logic - GL3523
Realtek - RTL8153
Eton Technology - EJ899T
Parade Technologies - PS176
ITE -IT6516
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Analog Resolutions: 1920 x 1200p @ 60Hz (VGA)
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 4096 x 2160p @ 24Hz or 3840 x 2160p @ 30Hz (HDMI)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
OS Compatibility:
Windows 7, 8, 8.1, 10
macOS 10.11 to 10.14
Chrome OS
