Question 1

I had MSI A320M Gaming pro and Ryzen 4 16000 CPU but it does not work, I was told that I have to upgrade the BIOS, but how should I do it without video output? Should I send it back to MSI for upgrading the BIOS?

Accepted Answer

The very first time it posts takes seemingly forever. it writes it's CMOS settings during that first post to whatever will work through what seems to be a trial and error method. You may have gotten that corrupted if you cycled the power or pressed the reset button too soon. I recommend you reset the CMOS with the jumper per the directions then, make sure your memory is on the manufacturer's list of tested ram modules then try again. This time. just let it do it's thing for the first post...as long as it takes. I remember my first post was almost 5 minutes and it seemed to reset itself 3 times. I believe memory compatibility is the biggest problem.  Have a flash drive ready with the latest bios ready for when if finally posts because, it will always be slow to post and will likely have memory compatibility issues until you flash the bios to the latest. After that, go into the bios settings again and find the preset for your ram that matches the ram manufacturers specs and select it. BTW you do need a video card. Try different outputs on the video card also. the one closest to the MB and video card board is usually default for pre-boot display.

Question 2

Will this board work with a ryzen 3 2200g?

Accepted Answer

As my experience it does not work, I search on internet some says it worked, and there are suggestions for checking how to make it work, I tried all ways and still not work, I have to change another type of CPU and finally it worked.

Question 3

what ram works with this?

Accepted Answer

Buy the MSI B350M Gaming PRO AM4 AMD B350 SATA 6Gb/s USB 3.1 HDMI Micro ATX AMD Motherboard for overclocking and G.SKILL Flare X (for AMD) 16GB (2 x 8GB) 288-Pin DDR4 SDRAM DDR4 2133 (PC4 17000) AMD X370 / B350 / A320 Desktop Memory Model F4-2133C15D-16GFX for ryzen.

Question 4

Does the motherboard come with the BIOS updated, or do I have to update it myself?

Accepted Answer

Mine came up to date, but I would always check for updates regardless.

Question 5

What is the size of the motherboard?

Accepted Answer

9.6 in. x 8.7 in. (24.4 cm x 21.0 cm)

Info available on manufacturer's website product page under specifications detail page.
You're welcome.

Question 6

I have a AMD FX 4300 CPU. Will it run with this motherboard?

Accepted Answer

FX 4300 is an AM3+ CPU, but this is an AM4 motherboard. AM4 motherboards are not backwards compatible with AM3+ CPUs.

Question 7

does this suport ryzen 3 1200?

Accepted Answer

It supports any AM4 processor, including the Ryzen 3 1200. My son has a 1600x on this board, and it works great.
If you need more than one video card or more than 2 sticks of DDR4, this board is not for you.

Question 8

Sorry for the noob question but what's the difference between this and the B350M Gaming Pro? First time builder trying to put together a Ryzen 5 1600 build and trying to find the right motherboard.

Accepted Answer

The main difference just from the title is that if you buy the B350M Gaming Pro you WILL be able to overclock your new CPU. the number and letters that you would normally see in the title of a motherboard indicates the type of chipset that the motherboard is using and will determine a variety of different aspects of the board but the main one for an AMD style build with a Micro ATX is that you will be able to overclock with a B350M. Other differences is that the B350M will only allow for a max (stock) RAM speed of 2667, however, this can be overclocked withing the motherboards BIOS but something to remember is that this is still a new chipset and a new CPU with quarks that are still being fixed. ALWAYS REMEMBER TO UPDATE YOUR BIOS when you get a new board for AMD. Another thing to remember is if you are making an AMD "budget" build than you HAVE TO HAVE a GPU (graphics card) as none of the Ryzen CPUs on the market have Integrated Graphics (meaning you can't use the HDMI, VGA, or DVI on the board whatsoever until the new AMD CPUs are released). Other than those differences (by looking at the specs of the board) you shouldn't have any problems with anything else on this build. So overall if you ARE going to overclock or if you plan on overclocking get the B350M Gaming Pro. IF you don't care about overclocking and just want it to work get the A320M Gaming Pro. If you do plan on overclocking make sure you purchase an aftermarket cooler for your CPU as the wraith spire that comes with the CPU is not built for overclocking and excess heat.

CPU Socket Type	AM4
CPU Type	Supports AMD RYZEN Series Processors and 7th Gen A-series/ Athlon processors for Socket AM4

Number of Memory Slots	2x288pin (DDR4)
Memory Standard	DDR4 3200(OC)/ 2933(OC)/ 2667/ 2400/ 2133/ 1866 * * 7th Gen A-series/ Athlon processors support up to DDR 2400 MHz only.
Maximum Memory Supported	32GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	1 x PCIe 3.0 x16 slots - RYZEN series processors support x16 mode - 7th Gen A-series/ Athlon processors support x8 mode
PCI Express x1	2 x PCIe 2.0 x1 slots

Serial ATA (SATA)	4 x SATA 6Gb/s
M.2	1 x M.2 slots (Key M) - Supports PCIe 3.0 x4 (RYZEN series processors) or PCIe 3.0 x2 (7th Gen A-series/ Athlon processors) and SATA 6Gb/s 2242/ 2260 /2280 storage devices
SATA RAID	0/1/10

Audio Chipset	Realtek ALC887
Audio Channels	7.1 Channels

Meet Your Seller

MSI A320M Gaming PRO AM4 AMD A320 USB 3.1 HDMI Micro ATX AMD Motherboard

Used - Very Good

Learn more about the MSI A320M Gaming PRO

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Back I/O Ports	1 x D-Sub / 1 x DVI-D / 1 x HDMI / 1 x LAN (RJ45) / 1 x PS/2 / 2 x USB 2.0/1.1 / 3 x Audio Jacks / 4 x USB 3.1 Gen 1
PS/2	1 x PS/2 keyboard/mouse port
Video Ports	1 x DVI-D 1 x VGA
HDMI	1 x HDMI
RJ45	1 x RJ45
USB 3.1	4 x USB 3.1 Gen1 Type-A ports
USB 1.1/2.0	2 x USB 2.0 Type-A ports
Audio Ports	3 Ports

Onboard USB	2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
Other Connectors	1 x 4-pin CPU fan connector 2 x 4-pin system fan connectors 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Serial port connector 1 x Parallel port connector 1 x Extended LED strip connector 1 x Clear CMOS jumper

Form Factor	Micro ATX
Dimensions (W x L)	9.6" x 8.7"
Power Pin	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector

Onboard LAN
LAN Chipset	Realtek 8111H
Max LAN Speed	1Gbps
