7th Gen processors support DDR4 2400/ 2133 6th Gen processors support DDR4 2133
Maximum Memory Supported
32GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express 3.0 x16
1 x PCI Express 3.0 x16
Other Slots
1 x M.2 Wi-Fi/ Bluetooth module vertical slot (Key E)
Storage Devices
Serial ATA (SATA)
4 x SATA 6Gb/s ports* * The SATA1 connector will be unavailable when an M.2 SATA SSD module has been installed in the M.2_2 slot.
M.2
1 x M.2 slot (Key M slot on the bottom of the motherboard) - Supports up to PCIe 3.0 x4 and SATA 6Gb/s - Supports 2242/ 2260 /2280 storage devices - Intel Optane Memory Ready
Onboard Audio
Audio Chipset
Realtek ALC887
Audio Channels
7.1 Channels
Onboard LAN
LAN Chipset
Realtek RTL8111H
Max LAN Speed
1Gbps
Wireless LAN
Wi-Fi/ Bluetooth expansion module with Intel Dual Band Wireless-AC 8265 chip - Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 867 Mbps speed.
Bluetooth
Supports Dual Mode Bluetooth 2.1, 2.1+EDR, 3.0, 4.0, BLE, 4.2
Rear Panel Ports
Back I/O Ports
1 x HDMI / 1 x PS/2 Keyboard/Mouse Combo / 2 x USB 2.0/1.1 / 4 x USB 3.1 Gen 2 Type-A
PS/2
1 x PS/2 keyboard/mouse port
Video Ports
1 x DVI-D port
HDMI
1 x HDMI
RJ45
1 x RJ45
USB 3.1
4 x USB 3.1 Gen1 Type-A ports
USB 1.1/2.0
2 x USB 2.0 Type-A ports
Audio Ports
3 Ports
Antenna Connectors
2 x antenna connectors
Internal I/O Connectors
Onboard USB
1 x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
Other Connectors
1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 2 x Front panel connectors 1 x TPM module connector 1 x Chassis Intrusion connector 1 x Serial port connector 1 x LED connecotr 1 x Clear CMOS jumper
Physical Spec
Form Factor
Mini ITX
Dimensions (W x L)
6.7" x 6.7"
Power Pin
24 Pin
Features
Features
Supports 7th / 6th Gen Intel Core / Pentium / Celeron processors for LGA 1151 socket
Supports DDR4-2400 Memory (Max.)
DDR4 Boost: Give your DDR4 memory a performance boost
VR Ready: Best virtual reality game experience without latency
Lightning Fast Game experience: Turbo M.2, Intel Optane Memory Ready
Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience
GAMING LAN: The best online gaming experience with lowest latency and bandwidth management
Military Class 4, Guard-Pro: Latest evolution in high quality components for best protection and efficiency
Mystic Light Sync: Synchronize other RGB solutions with your gaming rig and control all LEDs in one click
