4W 4000mW 802.11b/g/n Wifi Wireless Amplifier Router 2.4Ghz WLAN ZigBee Bluetooth Signal Booster with Antenna TDD for computer

4W 4000mW 802.11b/g/n Wifi Wireless Amplifier Router 2.4Ghz WLAN ZigBee Bluetooth Signal Booster with Antenna TDD for computer

This 2.4 GHz WLAN signal booster is designed for IEEE 802.11b/g/n wireless LAN applications. It adopts the direct sequence spread spectrum(DSSS) and orthogonal frequency division multiplexing(OFDM) technology of WLAN communication. The product is compatible with time-division duplexing(TDD) method of WLAN and using rapid microwave detection technology to provide high linearity amplification. The signal booster can work with most WLAN/WiFi devices, Bluetooth, ZigBee and increase the signal strength, therefore a larger WLAN coverage and more stable transmission rate.

Features:

20X the power, improving the quality and coverage of certified WLAN devices.

2.5dB ultra-low noise.

Wide 6-16V operating input range.

Working with certified IEEE 802.11b/g/n wireless LAN devices.

Simply plug and play, no software is required.

Specifications:

Frequency range: 2.4-2.5GHz

Operating voltage: 6-16V

Receiving gain: 10dB±1

Transmission gain: 13dB±1

Input trigger power: 3dBm(min), 20dBm(max)

Max output power(P1dB): 36dBm(4W)

EVM: 3%@28dBm 802.11g 54Mbps OFDM 64QAM BW 20MHz

DC supply current: 435mA @ Pout 28dBm 9V

Noise figure: <2.5dB

TX/RX switch time delay: <1us

LED indicator: Transmitter: green, receiver: red

Operating ambient temperature: -40~70

Operating humility: Up to 95% rel. humidity

Item size: 8.2 * 5 * 2.1cm / 3.22 * 1.96 * 0.82in (L * W * H)

Item weight: 181g / 6.39oz

Package size: 21 * 12.5 * 5cm / 8.26 * 4.92 * 1.96in (L * W * H)

Package weight: 381g / 13.43oz
