Cerwin Vega XED4004D || 4 Channel XED Series Amplifier / 400W MAX – XED4004D
- General Features :
- Latest High-Efficiency Class D Topology
- Compact Size with Ambient backlit logo
- RCA “Pass Thru” output for easy system expansion
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 O Stable Stereo and 4O Mono (CH3/4) for 3 Ch mode
- Proprietary Vega Bass Boost EQ Up To 12dB.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Latest High-Efficiency Class D Topology
Compact Size with Ambient backlit logo
RCA Pass Thru output for easy system expansion
Fully Variable Crossovers (12dB per octave)
Handles HI and LO level input to 12V
2 Stable Stereo and 4 Mono (CH3/4) for 3 Ch mode
Proprietary Vega Bass Boost EQ Up To 12dB
Max Power: 400 W MAX
RMS Power @ 2 ohm: 4 x 90W
RMS Power @ 4 ohm: 4 x 60W
Type: Class D
S-N Ratio (A weighted @ 1W): -85dBA
S-N Ratio (A weighted @ 1W): - 101.1 dBA
Sensitivity-Low Input Level: 250mV 6.0V
Sensitivity-High Input Level: 1.3V ~> 20.0V
Power Supply: Full PWM
Power Supply Threshold: 10.0DVC 16.0DVC
Idle Current: ( 0.7A )
THD 4 (1KHz @4): <0.1%
Impedance-Low Input Level: 10 K
Impedance-High Input Level: 100 K
Output Impedance: 2 K
Damping Factor (50Hz @ 4) >70
Bandwidth (-3dB) 10Hz-30KHz
Crossover (-12 dB/ Oct) Variable High Pass: 35Hz-250Hz
Crossover (-12 dB/ Oct) Variable Low Pass: 35Hz-250Hz
Fuse Rating ATC (inside) 30A
Dimentions (L x W x H): 6.3 x 4.7 x 1.8 [160mm x 120mm x 46.5 mm]
Compact Size with Ambient backlit logo
RCA Pass Thru output for easy system expansion
Fully Variable Crossovers (12dB per octave)
Handles HI and LO level input to 12V
2 Stable Stereo and 4 Mono (CH3/4) for 3 Ch mode
Proprietary Vega Bass Boost EQ Up To 12dB
Specifications
Max Power: 400 W MAX
RMS Power @ 2 ohm: 4 x 90W
RMS Power @ 4 ohm: 4 x 60W
Type: Class D
S-N Ratio (A weighted @ 1W): -85dBA
S-N Ratio (A weighted @ 1W): - 101.1 dBA
Sensitivity-Low Input Level: 250mV 6.0V
Sensitivity-High Input Level: 1.3V ~> 20.0V
Power Supply: Full PWM
Power Supply Threshold: 10.0DVC 16.0DVC
Idle Current: ( 0.7A )
THD 4 (1KHz @4): <0.1%
Impedance-Low Input Level: 10 K
Impedance-High Input Level: 100 K
Output Impedance: 2 K
Damping Factor (50Hz @ 4) >70
Bandwidth (-3dB) 10Hz-30KHz
Crossover (-12 dB/ Oct) Variable High Pass: 35Hz-250Hz
Crossover (-12 dB/ Oct) Variable Low Pass: 35Hz-250Hz
Fuse Rating ATC (inside) 30A
Dimentions (L x W x H): 6.3 x 4.7 x 1.8 [160mm x 120mm x 46.5 mm]
