Camera Image Sensor 1/3" Progressive Scan CMOS Min. Illumination 0.028 Lux @ (F 2.0, AGC ON), 0 Lux with IR Shutter Speed 1/3 s to 1/10, 000 s Lens 2.8 mm, horizontal
FOV: 98°, vertical
FOV: 55°, diagonal
FOV: 114° Lens Mount M12 Day & Night IR cut filter with auto switch DNR 3D DNR Wide Dynamic Range True WDR 120dB
Angle Adjustment Pan: 0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360° Compression Standard Video Compression
Main stream: H. 265/ H.
264 Sub stream: H. 265/H.
264/ MJPEG Third stream: H. 265/ H. 264 H. 264 / H. 264+ Type Main Profile / High Profile / Main Stream and Sub Stream Support H. 265 / H. 265+ Type Main Profile / Main stream and sub stream support Video Bit Rate 32 Kbps ~ 16 Mbps Dual Stream Support Image Max. Resolution 2560 × 1440
Main Stream 50Hz: 25fps (2560×1440, 2304×1296, 1920×1080)
60Hz: 30fps (2560×1440, 2304×1296, 1920×1080)
Sub Stream 50Hz: 25fps (640 × 480, 640 × 360, 320
× 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream 50Hz: 25fps (1280×720, 640×360, 352×288)
60Hz: 30fps (1280×720, 640×360, 352×240) Behavioral Analysis Line crossing detection, intrusion detection Network Network Storage Support microSD/SDHC/SDXC card (128G), local storage and NAS (NFS, SMB/CIFS), ANR Alarm Trigger Motion Detection, Tampering Alarm, Intrusion Detection, Line Crossing Detection, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted Protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour General One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter Standard ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI Interface Communication Interface 1 RJ45 10M/100M Ethernet port Reset Yes General Working Temperature /Humidity -22 °F ~ 140 °F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) Power Supply DC12V ± 25%, Power Consumption 12 VDC, 0.5A, Max. 6W IR Range Up to 100ft Weather Proof Ratings IP67 Dimensions 5.01? × 3.78? (F 127.3 × 95.9 mm) Weight 1.3 lb.
(610g)
