Camera Image Sensor 1/3" Progressive Scan CMOS Min.
Illumination Color: 0.018 Lux @ (F 1.6, AGC ON), 0 Lux with IR Shutter Speed 1/3 s to 1/100, 000 s Slow Shutter Yes Day & Night IR Cut Filter WDR 120 dB
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° Lens Lens Type Fixed lens, 2.8 mm Aperture F 1.6
FOV 2.8 mm: Horizontal
FOV: 103°, vertical
FOV: 58°, diagonal
FOV: 123° Lens Mount M12 Illuminator IR Range Up to 98ft (30 m) Wavelength 850 nm Video Max. Resolution 2688 × 1520
Main Stream 50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280
× 720) 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
Sub Stream 50Hz: 25fps (640 × 480, 640 × 360, 320
× 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream 50Hz: 25fps (1280 × 720, 640 × 360, 352
× 288) 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) Video Compression
Main stream/third stream: H. 265/H.
264 Sub-stream: H. 265/H. 264/MJPEG H. 264 Type Main Profile/High Profile H. 264+ Main stream supports H. 265 Type Main Profile H. 265+ Main stream supports Video Bit Rate 32 Kbps to 16 Mbps Scalable Video Coding (SVC) H. 264 and H. 265 encoding Audio Audio Compression G. 711/G. 722.1 /G. 726/MP2L2/PCM/MP3 Audio Bit Rate 64Kbps(G. 711)/16Kbps(G. 722.1 )/16Kbps(G. 726)/32-192Kbps (MP2L2) /8Kbps-320Kbps (MP3) Environment Noise Filtering Yes Audio Sampling Rate 8 kHz/16 kHz/32 kHz/ 44.1 kHz/48 kHz
