Specifications: Product Type: Handheld Terminal OS:windows 10 pro CPU: intel cherry trail Z8350 RAM/ROM: 4GB 64GB LCD: 10.1 inch 1080*1920; 500 nits sunshine readable Touch screen: 10 points touch Camera: front 2.0MP, rear camera: 5.0mp Battery: 5000mAh battery, 3.5*1.35mm, 5V 3A DC in put WLAN: 4G LTE, 3G WCDMA, GSM FDD: B1,B2, B3,B5, B7, B8, B12, B20 TDD: B38,B39,B40,B41, B34 WCDMA:B1, B8 TD-SCDMA: B34, B39 GSM/GPRS/EDGE Support GPS: Baidou + GPS, or glonass optional WIFI: 802.11a b c, g,n wireless internet Wireless AP ( Mobile AP )2.4G, 5G, intel 3165 BLUETOOTH: 4.0 version Built-in NFC: 13.56 MHz, distance 0-5cm or above SPEAKER: 1.5 watt Machine size:180*87*21.5mm Multi-media: (Hardware decoding) Photo Viewer BMP, JPG, GIF, PNG Video Format MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG. (UP TO 1080P) Audio Format MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3,DTS (need license) Language: Support multi language Interface: in/out port: 1.USB3.0*1 2. Micro USB*1 3. microphone+earphone 4. bottom pogopin*1, 5. back pogopin*1, USB and serial 6. DC*1 3.5*1.35 Pogo pin definition: 1.16pin back of cover, including (1USB, 1 RS232, 1 UART, 3.3V, 5V) 2. 8pin in bottom; (1USB, 1 RS232, 1 UART, 5V) Casing material: ABS/PC/rubber TPU/aluminum Buttons: Volume +,Volume -, Power button, barcode scanner, H Accessories in box: 1. 4-in-1 charger 2. hand strap accessories optional: 1. docking station 2. car charger 7. blue box, no logo Proof rate: 1. water proof IP65 2. Dropping proof 1.2 meter Temperature: 1.storage temperature: -25 to +80 2.operation temperature: -20 to +60
