M.2 NVMe SSD NGFF to PCIe x4 Adapter Card M key+B key Dual Interface Card

Description LRNV9511 adapter card is one of the only cards that supports both PCIe and SATA-based M.2 SSDs (solid-state drives). Its a versatile way to expand the overall storage capacity of your desktop PC or server. Besides, it supports a high speed PCIe M.2 drive so you can increase the speed and performance of your computer.

SpecThis M.2 NVMe+SATA adapter card is one of the only cards that supports both PCIe and SATA-based M.2 SSDs (solid-state drives). Its a versatile way to expand the overall storage capacity of your desktop PC or server. Moreover, it supports a high-speed PCIe M.2 drive, so you can increase the speed and performance of your computer.

SpecificationModel: LRNV9511

Bus Type: PCI Express 3.0 x4

Connector: M.2 M-Key+B-Key

Support device: 1*M.2 NVMe+1*M.2 SATA

LED Indicators: 3 - M.2 drive status/activity

1 - Power Supply

Dimension: 120*69*20mm

Humidity: 20%~80% RH (Non-condensing)

Operating Temperature: 5°C to 50°C (41°F to 122°F)

Storage Temperature: -25°C to 70°C (-13°F to 158°F)

Dimension: 139mm*69mm

Weight: 2.3 oz [65 g]

Warranty: 2 Years

WHAT'S IN THE BOX

1 - M.2 PCIe SSD Adapter

1 - high-profile bracket (installed)

1 - low-profile bracket

2 - screw&nut for M.2 ssd

1 - Warranty Card
