UR85 / UR85HD BUSHIDO 85mm Crazybee F4 PRO 2-3S Whoop Cinewhoop FPV Racing Drone OSD 5.8G 25~200mW VTX

UR85 / UR85HD BUSHIDO 85mm Crazybee F4 PRO 2-3S Whoop FPV Racing Drone OSD 5.8G 25~200mW VTX

Specification

Brand name



Item name

UR85

UR85HD

Wheelbase

85mm

85mm

Motor

Mode: 0805 KV9000

Configu-ration:9N12P

Stator Diamter:8mm

Stator Length:5mm

Shaft Diameter:1.5mm

Motor Dimension(Dia.*Len):10.5mm*17mm

Weight(g):3.0g

No.of Cells(Lipo):1S-3S

Mode: 1102 KV9000

Configu-ration:9N12P

Stator Diamter:11mm

Stator Length:2mm

Shaft Diameter:1.5mm

Motor Dimension(Dia.*Len):13.5mm*16mm

Weight(g):2.8g

No.of Cells(Lipo):1S-3S

Camera

Caddx EOS2

1/3" CMOS Sensor

1200 TVL

2.1mm lens

16:9 Image size

NTSC

Global WDR

Internal Synchronization

CADDX Turtle V2

Image sensor: 1/2.7" CMOS sensor

Horizontal: 800TVL

TV system: NTSC/PAL changeable

Video Resolution: 1080P@60fps / 1080P@30fps / 720@60fps

Power Input: DC 4.5-20V

FPV FOV: 155°

Recording FOV: 170°

Mini Illumination: 0.01lux

Image Resolution: 2 Megapixels

Lens: 1.8mm Turbo Eye Lens

Working Current: 380mA@5V/160mA@12V (low consumption)

OSD Menu: Yes (Support Voltage Display)

Video Files: MP4

Audio: Support

Electronic Shutter : PAL : 1/50-100,000 NTSC : 1/60-100,100

S/N Ratio: >60dB (AGC OFF)

Video Output: CVBS

Max Micro SD Card Supported: 8-64GB(need Class 10 or above, recommend Class 10/UHS-I/UHS-II)

Color: Red

Flight controller

( version) CRAZYBEE F4FR PRO V2.0 Firmware target: CrazybeeF4FR

( version) CRAZYBEE F4FS PRO V2.0 Firmware target: CrazybeeF4FS

(DSM2/DSMX version) CRAZYBEE F4DX PRO V2.0 Firmware target: CrazybeeF4DX
