SILVERSTONE Sugo Series SST-SG08B Black Aluminum Mini-ITX Desktop Computer Case 600W 80+ Bronze Certified / Single +12V rail Power Supply

OUT OF STOCK.
  • 10mm aluminum front panel, SECC body Mini-ITX Desktop
  • USB 3.0 x 2 Audio x 1 MIC x 1 Front Ports
  • 600W Power Supply
  • Side Air duct
  • 1 Internal 3.5" Drive Bays
Overview
Specs
Reviews

INTRODUCTION

SST-SG08B

To further increase the appeal of the groundbreaking Sugo SG07, SilverStone engineers crafted a follow-up version in the SG08. For the first time in a SilverStone product and likely also the first for Mini-ITX, a 0.4-inch (1cm) thick extruded aluminum was used to adorn the front panel of a chassis. Finished with fine brush surface and anodized, the SG08's front panel rivals the best home theater equipment in quality and style. The award winning and proven features from the SG07 remain such as the Air Penetrator AP181 fan with dual speed switch, easily removable fan filter, positive pressure layout, and the included 80 PLUS Bronze certified 600W power supply. While compact in size at only about 900 cubic inches (14.8 liters), the SG08 is still capable of accepting a healthy selection of full size components. Even the longest consumer graphics cards up to 12.2 inches can fit. This extraordinary capacity, along with the cooling power provided by the built-in AP181 fan, makes the SG08, along with SG07, the ultimate Mini-ITX chassis.


SPECIAL FEATURES

SST-SG08B
  • Thick 10mm aluminum front panel with premium styling
  • Class leading SFF chassis with 180mm fan and positive pressure cooling
  • Ample space for CPU cooling (117mm in height)
  • Elevated standoff for motherboard back side components
  • Support for two 2.5" SSDs/HDDs and one 3.5" hard drive
  • Includes 80 PLUS Bronze certified 600W @ 122°F (50°C) PSU with single +12V rail
  • Adjustable VGA fan duct for improved cooling efficiency
  • Removable fan filters included for case fan, PSU, and VGA duct
  • Support graphics cards up to 12.2 inches and 400W

SST-SG08B
  • AMD Radeon HD 5970 – 12.2"
  • AMD Radeon HD 6990 – 12"
  • AMD Radeon HD 6970 – 11"
  • AMD Radeon HD 6950 – 11"
  • NVIDIA GeForce GTX690 – 11"
  • AMD Radeon HD 6870 – 10.5"
  • NVIDIA GeForce GTX580 – 10.5"
  • NVIDIA GeForce GTX680 – 10"
  • NVIDIA GeForce GTX670 – 9.5"
  • AMD Radeon HD 6850 – 9"


SST-SG08B
  1. One Air Penetrator 180mm fan (AP181) included for superior cooling performance
  2. Dual speed fan switch and reset button on rear panel
  3. Two full size expansion slots accommodates top-end graphics card up to 12.2" long
  4. Supports Mini-DTX and Mini-ITX motherboards
  5. GPU vent divider prevents air exhaust recycling back into PSU
  6. PSU filter included
  7. Custom 600W PSU (80 PLUS Bronze certified) with short cables included
  8. Accommodates one 3.5" hard drive and two 2.5" hard drives or SSDs
  9. One slim optical drive bay included
  10. Thick 10mm aluminum front panel with premium styling
  11. Slide-out removable top 180mm fan filter included

SPECIFICATIONS

Model No.
SST-SG08B (black)
--
--
--
Material 10mm Aluminum front panel, SECC body
Motherboard DTX, Mini-ITX
Multimedia --
Drive Bay External Slim optical x 1
--
Internal 3.5" x 1, 2.5" x 2
Cooling System Front --
Rear --
Side VGA fan duct with oversized vents
Top 180mm Air Penetrator 700/1200RPM, 18/34dBA
Bottom PSU intake vents and VGA exhaust divider
Internal --
Expansion Slot 2
Front I/O Port
  • USB 3.0 x 2
  • Audio x 1
  • MIC x 1
Power Supply Custom 600W with 80 PLUS Bronze certification and single +12V rail
Operating System Support --
Expansion Card Support expansion cards up to 12.2 inches, width restriction - 4.38"
Maximum CPU Cooler Size 117mm
Limitation of PSU 140mm (remove VGA Card if you want install up to 170mm)
Net Weight 13.2lbs (6kg)
Dimensions (W x H x D) 8.75 x 7.5 x 13.8 inches (222 x 190 x 351mm)
Approx. 900Cu. In. (14.8 liters)
Extra --
Support VESA Mount --
Model No. SST-ST60F-SG
Max. DC Output 600W
Load Range
  +3.3V +5V +12V1 +12V2 +12V3 +12V4 +5VSB -12V -5V
Max. (Amps) 25A 25A 46A / / / 3.0A 0.8A /
Min. (Amps) 0.8A 0.5A 4A / / / 0.1A 0A /
Range (%) ±5% ±5% ±5% / / / ±5% ±10% /
Ripple (mVp-p) 50mV 50mV 120mV / / / 50mV 120mV /
combined +3.3, +5V 140W
combined +12V 46A / 552W
Input Voltage 90 ~ 265V (Auto Range)
Input Frequency Range 47Hz - 63Hz
PFC Active PFC (PF > 0.95 at full load)
Efficiency 82 - 85% at 20 - 100% loading
MTBF 100,000 hours at 77°F (25°C), full load
Operating temperature 50 - 122°F (10 - 50°C)
Protection
  • Over Current Protection
  • Over power Protection
  • Over Voltage Protection
  • Under Voltage Protection
  • Short Circuit Protection
Connectors
  • 1 x 24 / 20-Pin Motherboard connector (670mm)
  • 1 x 8 / 4-Pin EPS / ATX 12V connector (670mm)
  • 1 x 8 / 6-Pin PCIE connector (360mm)
  • 1 x 8 / 6-Pin PCIE connector (380mm)
  • 3 x SATA connector (350mm + 130mm + 150mm)
  • 2 x 4-Pin Peripheral connector (350mm + 100mm)
Color Black (Lead-Free Paint)
Cooling System Single 120mm fan
Noise Level 17dBA - 30dBA
Dimensions (W x H x D) 6 x 3.3 x 5.5 inches (150 x 86 x 140mm)
Weight 2lbs (940g)
Form Factor ATX12V / EPS12V
Certification 80 PLUS Bronze
