Brand | GIGABYTE |
---|---|
Model | GA-Z68AP-D3(R2.0) |
CPU Socket Type | LGA 1155 |
---|---|
CPU Type | Core i7 / i5 / i3 / Pentium / Celeron (LGA1155) |
Chipset | Intel Z68 |
---|
Onboard Video Chipset | Supported only by CPU with integrated graphic |
---|
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR3 2133/1866/1600/1333/1066 |
Maximum Memory Supported | 32GB |
Channel Supported | Dual Channel |
PCI Express 3.0 x16 | 2 (x16, x4) (All PCI Express x16 slots conform to PCI Express 3.0 standard. To support PCI Express 3.0, you must install an Intel 22nm CPU. ) |
---|---|
PCI Express x1 | 3 x PCI Express x1 |
PCI Slots | 2 x PCI Slots |
SATA 3Gb/s | 3 x SATA 3Gb/s |
---|---|
SATA 6Gb/s | 2 x SATA 6Gb/s |
SATA RAID | 0/1/5/10 |
Audio Channels | 8 Channels |
---|
LAN Chipset | Realtek 8111E |
---|---|
Max LAN Speed | 10/100/1000Mbps |
PS/2 | 1 x PS/2 keyboard/mouse port |
---|---|
COM | 1 |
LPT | 1 |
HDMI | 1 x HDMI |
USB 3.0 | 2 x USB 3.0 |
USB 1.1/2.0 | 4 x USB 2.0 |
S/PDIF Out | 1 x Optical |
Audio Ports | 3 Ports |
Onboard USB | 6 x USB 2.0 |
---|---|
Other Connectors | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x mSATA connector 1 x CPU fan header 2 x system fan headers 1 x power fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x clearing CMOS jumper 1 x Trusted Platform Module (TPM) header |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12" x 8.46" |
Power Pin | 24 Pin |
Features | Onboard mSATA connector and Smart Response Technology GIGABYTE EZ Smart Response Built-in Visuals GIGABYTE Touch BIOS PCI Express Gen.3 Support 50,000 Hours Japanese Solid Capacitors New 100% Hardware VRD 12 Compliant CPU Power Design |
---|
Date First Available | April 11, 2022 |
---|
