Brand | ASUS |
---|---|
Model | P5K |
CPU Socket Type | LGA 775 |
---|---|
CPU Type | Core 2 Quad / Core 2 Extreme / Core 2 Duo |
FSB | 1333/1066 MHz |
Chipset | Intel P35 |
---|---|
South Bridge | Intel ICH9 |
Onboard Video Chipset | None |
---|
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR2 1066/800 / 667 MHz The chipset officially supports the memory frequency up to DDR2 800MHz. Tuned by ASUS Super Memspeed Technology, this motherboard natively supports up to DDR2 1066MHz |
Maximum Memory Supported | 8GB |
Channel Supported | Dual Channel |
PCI Express x16 | 2 x PCI-E x16 (blue @ x16 mode, black @ x4 or x1 mode) |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 3 x PCI Slots |
PATA | 1 x ATA100 2 Dev. Max |
---|---|
SATA 3Gb/s | Southbridge 4 x SATA 3.0 Gb/s ports JMicron JMB363 controller 1 x SATA 3.0 Gb/s ports 1 x External SATA 3.0 Gb/s port (SATA On-the-Go) |
SATA RAID | 1 x SATA and 1 x eSATA ports (offer by JMicron JMB363) Support RAID 0/1 |
Audio Chipset | Realtek ALC 883 |
---|---|
Audio Channels | 8 Channels |
Max LAN Speed | 10/100/1000Mbps |
---|
PS/2 | 1 |
---|---|
USB 1.1/2.0 | 6 x USB 2.0 |
IEEE 1394 | 1 x IEEE 1394a |
Audio Ports | 6 Ports |
Onboard USB | 6 x USB 2.0 |
---|---|
Onboard 1394 | 1 x 1394a |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12.0" x 9.6" |
Power Pin | 24 Pin |
Features | Supports CrossFire Technology ASUS Super Memspeed Technology- Memory speed enhanced up to 75%! AI Slot Detector- Plug and Proof detector for PCIe/PCI slots AI Gear 2 – Save 50% CPU Power Stack Cool 2 – Up to 20°C/36°F Cooler ASUS Fanless Design Heap Pipe |
---|
Windows Vista | Certified for Windows Vista |
---|
Date First Available | June 04, 2007 |
---|
Pros: No problems installing this board. Posted perfectly the first time, everything worked with the first power up and have experienced no problems whatsoever so far. P5K with Intel 6850, Zalman 9700, 4G Crucial Ballistix, Antec 900, EN8600GT, SG 320G, Enermax ELT500 with Vista Business 64 bit in this case. Very fast and stable. No driver issues at all with any of the components. Have not attempted overclocking. Very pleased with Newegg. Great selection and prices. Everything arrived in 4 days in great shape. Couldn't be happier.
Cons: As metioned by others, EIDE socket location could be better. But, the cable was long enough to reach one drive installed near the top of the case. Not a neat arrangement by any means though.
Overall Review: Carefully considered purchase of a complete system as opposed to purchasing components separately to replace a tired system I used at home for extended work/business. I really don't build these things for a hobby. But, as stated above, I couldn't be happier with the outcome and Newegg's selection and service.
