ASUS P5E Deluxe LGA 775 Intel X48 ATX Intel Motherboard

(95) Write a Review
  • Intel X48
  • Core 2 Quad / Core 2 Extreme / Core 2 Duo
  • DDR2 1200(O.C) / 1066
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews (95)

Learn more about the ASUS P5E Deluxe

Model
Brand ASUS
Model P5E Deluxe
Supported CPU
CPU Socket Type LGA 775
CPU Type Core 2 Quad / Core 2 Extreme / Core 2 Duo
FSB 1600/1333 MHz
Chipsets
Chipset Intel X48
South Bridge Intel ICH9R
Onboard Video
Onboard Video Chipset None
Memory
Number of Memory Slots 4x240pin
Memory Standard DDR2 1200(O.C) / 1066
Maximum Memory Supported 8GB
Channel Supported Dual Channel
Expansion Slots
PCI Express 2.0 x16 2 x PCI Express 2.0 x16
PCI Express x1 3 x PCI Express x1
PCI Slots 2 x PCI Slots
Storage Devices
PATA 1 x ATA100 2 Dev. Max
SATA RAID 0/1/5/10
Onboard Audio
Audio Chipset ADI AD1988B
Audio Channels 8 Channels
Onboard LAN
LAN Chipset Marvell 88E8056
Max LAN Speed 1Gbps
Rear Panel Ports
Back I/O Ports 1 x Optical S/PDIF Out / 1 x PS/2 / 1 x S/PDIF Coaxial Out / 6 x USB 2.0/1.1
PS/2 1
USB 1.1/2.0 6 x USB 2.0
IEEE 1394 1 x IEEE 1394a
S/PDIF Out 1 x Optical, 1 x Coaxial
Internal I/O Connectors
Onboard USB 3 x USB connectors support additional 6 USB ports
Onboard 1394 1 x 1394a
Physical Spec
Form Factor ATX
Dimensions (W x L) 12.0" x 9.6"
Power Pin 24 Pin
Packaging
Package Contents P5E Deluxe
Driver Disk
User Manual
Rear I/O Panel Shield
SupremeFX II Audio Card
IDE/PATA Cable
FDD Cable
SATA Cable
4-pin to SATA Power Cable
IEEE 1394 & USB Bracket
Optional Fan
Additional Information
Date First Available June 18, 2008

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year
  • Read full details

Return Policies

  • Return for refund within: Non-refundable
  • Return for replacement within: 30 days
  • This item is covered by Newegg.com's Replacement Only Return Policy. Read full return policy for details.
