ASUS Z97I-PLUS LGA 1150 Intel Z97 HDMI SATA 6Gb/s USB 3.0 Mini ITX Intel Motherboard

Name: ASUS Z97I-PLUS LGA 1150 Intel Z97 HDMI SATA 6Gb/s USB 3.0 Mini ITX Intel Motherboard
Brand: ASUS
SKU: N82E16813132122
Price: 204.99 USD
Availability: InStock

Used - Like New

See more "lga 1150 motherboard asus"

In stock.

Ships from United States.

Intel Z97
Core i7 / i5 / i3 / Pentium / Celeron (LGA1150)
DDR3 3200(OC)/3100(OC)

Specs

Learn more about the ASUS Z97I-PLUS

Model
Brand	ASUS
Model	Z97I-PLUS

Supported CPU
CPU Socket Type	LGA 1150
CPU Type	Core i7 / i5 / i3 / Pentium / Celeron (LGA1150)

Chipsets
Chipset	Intel Z97

Onboard Video
Onboard Video Chipset	Supported only by CPU with integrated graphic

Memory
Number of Memory Slots	2×240pin
Memory Standard	DDR3 3200(OC)/3100(OC)/3000(OC)/2933(OC)/2800(OC)/2666(OC)/2600(OC)/2500(OC)/2400(OC)/2200(OC)/2133(OC)/2000(OC)/1866(OC)/1800(OC)/1600/1333
Maximum Memory Supported	16GB
Channel Supported	Dual Channel

Expansion Slots
PCI Express 3.0 x16	1 x PCI Express 3.0 x16

Storage Devices
SATA 6Gb/s	4 x SATA 6Gb/s
M.2	1 x M.2 Socket 3 with M Key
SATA RAID	0/1/5/10

Onboard Audio
Audio Chipset	Realtek ALC892
Audio Channels	8 Channels

Onboard LAN
LAN Chipset	Intel I218-V
Max LAN Speed	10/100/1000Mbps
Wireless LAN	Wi-Fi 802.11 ac
Bluetooth	Bluetooth 4.0

Rear Panel Ports
PS/2	1 x PS/2 keyboard/mouse port
Video Ports	1 x DVI-D 1 x VGA
HDMI	1 x HDMI
DisplayPort	1 x DisplayPort
USB 3.0	4 x USB 3.0
USB 1.1/2.0	4 x USB 2.0
S/PDIF Out	1 x Optical

Internal I/O Connectors
Onboard USB	2 x USB 3.0 + 2 x USB 2.0
Other Connectors	1 x 24-pin EATX Power connector 1 x 8-pin EATX 12V Power connector 1 x CPU Fan connector (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) CPU coolers control with auto detection support 2 x Chassis Fan connectors (4-pin) for both 3-pin(DC mode) and 4-pin(PWM mode) coolers control 1 x System Panel connector (with Q-Connector) 1 x Front panel audio connector (AAFP) 1 x clear CMOS jumper 1 x S/PDIF out header 1 x speaker header 1 x TPM header 1 x MemOK! Button

Physical Spec
Form Factor	Mini ITX
Dimensions (W x L)	6.7" x 6.7"
Power Pin	24 Pin

Features
Features	ASUS 5X Protection -ASUS motherboards safeguard your PC with 5X Protection: DIGI+ Power Control, DRAM Fuse, ESD Guards, High-Quality Solid Capacitors, and Stainless Steel Back I/O to ensure the best quality, reliability, and durability. ASUS DIGI+Power Control -CPU Power -Industry leading 6-phase power design -ASUS CPU power utility -DRAM Power -Industry leading 2-phase DRAM power design -ASUS DRAM power utility ASUS DRAM Fuse -Enhanced DRAM overcurrent protection and short circuit damage prevention ASUS ESD Guards -Strong ESD protection for extended component lifespan ASUS High-Quality Solid Capacitors -2.5x Longer lifespan with excellent durability ASUS Stainless Steel Back I/O -3x More durable corrosion-resistant coating Fan Xpert 3 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control UEFI BIOS-Most advanced options with fast response time M.2 onboard-The latest transfer technology with up to 10Gb/s data-transfer speeds ASUS HomeCloud Server ASUS Wi-Fi GO! -Wi-Fi GO! Function: Cloud GO!, Remote Desktop, Remote Keyboard & Mouse, File Transfer -Wi-Fi GO! Remote app for portable smartphone/tablet, supporting iOS 7 & Android 4.0 systems Media Streamer -Pipe music or movies from your PC to a smart TV, your entertainment goes wherever you go! -Media Streamer app for portable smartphone/tablet, supporting iOS 7 & Android 4.0 systems Turbo LAN -Experience smooth online gaming with lower pings and less lags ASUS Audio Feature -Feel the sound power with different usage scenarios. Push Notice-Monitor your PC status with smart devices in real time USB BIOS Flashback with USB BIOS Flashback Wizard for EZ BIOS download scheduling UEFI BIOS EZ Mode featuring friendly graphics user interface -O.C. Tuner -CrashFree BIOS 3 -EZ Flash 2 Q-Design -ASUS Q-Shield -ASUS Q-Slot -ASUS Q-DIMM -ASUS Q-Connector

Packaging
Package Contents	ASUS Z97I-PLUS Motherboard 1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x 2-in-1 Wi-Fi antenna connector 4 x Serial ATA 6.0Gb/s cables 1 x ASUS Q-Shield 1 x ASUS Q-Connector 1 x User Manual

Additional Information
Date First Available	January 18, 2019
