ASRock Z87 Extreme6/ac LGA 1150 Intel Z87 HDMI USB 3.0 ATX Intel Motherboard
- Intel Z87
- 4th-Gen Intel Core i7 / i5/ i3 (LGA1150)
- DDR3 2933+(OC)/2800(OC)
Overview
Specs
Reviews (21)
ASRock Z87 Extreme6/ac
- A-Style: Home Cloud, Purity Sound™, 802.11ac Wi-Fi, HDMI-In
- Supports 4th Gen Intel® Core™ i7 / i5 / i3 / Xeon® / Pentium® / Celeron® in LGA1150 Package
- Premium Gold Capacitor Design, Digi Power, 12 Power Phase Design, Dual-Stack MOSFET
- Supports Dual Channel DDR3 2933+(OC)
- Three PCIe 3.0 x16, one PCIe 2.0 x1, one mini-PCIe
- Supports AMD Quad CrossFireX, 3-Way CrossFireX, CrossFireX
- Supports NVIDIA® Quad SLI and SLI
- Multi VGA Output Options: DVI-I, HDMI, DisplayPort
- Intel® Dual Gigabit LAN with Teaming
- 7.1-Channel HD Audio with Content Protection (Realtek ALC1150 Audio Codec), Supports DTS Connect
- Ten SATA3, one eSATA, eight USB 3.0, seven USB 2.0
- One Front USB 3.0 Panel with 2.5" HDD/SSD Rack, one Rear USB 3.0 Bracket
- WLAN: one 802.11ac Wi-Fi + BT v4.0 module, one ASRock Wi-Fi 2.4 / 5GHz Antenna
- Supports A-Tuning, XFast 555, Easy Driver Installer, Fan-Tastic Tuning, USB Key
Home Cloud - Remote Desktop Anytime, Anywhere
This motherboard supports remote-wake with the onboard Intel® LAN, so you can connect with your PC from anywhere in the world. You will be able to power your PC on or turn it off, monitor and take control of it remotely with another smartphone, tablet or computer.
Note: Intel® Remote Wake is supported on Windows 8 / 64-bit OS.
Use your Home Cloud for the following real world scenarios:
Keep your stored mail near at hand whenever you need it.
Multimedia
Stream your secret stash of vids, music and pics.
Documents
Access or send files remotely anywhere.
TV
Watch your favorite local TV programs by connecting to your PC.
Monitor
Keep an eye on your pets or children when you are away from home.
Configure different fan speeds for respective temperatures using the graph. The fans will automatically shift to the next speed level when the assigned temperature is met.
For users that don't have an optical disk drive to install the drivers from our support CD, Easy Driver Installer is a handy tool in the UEFI that installs the LAN driver to your system via an USB storage device, then downloads and installs the other required drivers automatically.
In a world where time is money, why waste precious time everyday typing usernames to log in to Windows? Why should we even bother memorizing those foot long passwords? Just plug in the USB Key and let your computer log in to windows automatically!
With ASRock's exclusive Fast Boot technology, it takes less than 1.5 seconds* to logon to Windows® 8 from a cold boot. No more waiting! The speedy boot will completely change your user experience and behavior.
*The boot time may vary with a different configuration.
Contact ASRock Tech Service by sending a support request from the UEFI setup utility if you are having trouble with your PC.
UEFI system browser is a useful tool included in graphical UEFI. It can detect the devices and configurations that users are currently using in their PC. With the UEFI system browser, you can easily examine the current system configuration in UEFI setup.
ASRock "Restart to UEFI" technology is designed for those requiring frequent UEFI access. It allows users to easily enter the UEFI SETUP automatically when turning on the PC next time.
Users may prevent motherboard damages due to dampness by enabling "Dehumidifier Function". When enabling Dehumidifier Function, the computer will power on automatically to dehumidify the system after entering S4/S5 state.
ASRock Online Management Guard (OMG) technology allows you to establish an internet curfew or restrict internet access at specified times. Administrators are able to schedule the starting and ending hours of internet access granted to other users.
This motherboard supports High-Definition Multimedia Interface™ (HDMI) which is an interface standard for transferring uncompressed video data and delivering multi-channel audio through a single cable. Both video and audio data signals transferred through the HDMI™ interface are digital without being converted into analog, therefore it delivers the richest pictures and the most realistic sounds.
Purity Sound is a combination of several hardware, software audio solutions and technologies that will satisfy even the pickiest audiophiles. Including 7.1-Channel HD audio with Realtek ALC1150 audio codec, 115dB SNR DAC with Differential Amplifier, TI® 5532 Premium Headset Amplifier which supports up to 600 ohm headphones, cap less Direct Drive technology, EMI shielding cover, PCB isolate shielding and support for DTS Connect.
Purity Sound™ brings you:
- 115dB SNR
- Excellent Bass
- Less Sound Distortion
- More Details
- Supports up to 600Ω headphones
Traditional Audio Solution:
- 110dB SNR
- Poor Bass
- More Sound Distortion
- Less Details
- Does not support high impedance headphones
This frequency response chart is tested under 32 Ohm loading to simulate normal headphones. It indicates how traditional audio solution's frequency response drops drastically at low frequencies, while Purity Sound™ maintains its frequency response and provides better bass with the TI® NE5532 amplifier.
Tired of constantly switching devices to connect to your one and only monitor? From now on just connect the monitor to your motherboard, and connect your secondary device (such as a PS3 or Xbox) to the motherboard's HDMI-In port. With HDMI-In users may conveniently toggle between the computer's screen and the secondary device's screen with a hotkey, or even use their secondary device without powering on the computer.
This motherboard comes with an exclusive 802.11ac Wi-Fi (5G Wi-Fi) module that supports up to 867Mbps wireless networks and Bluetooth v4.0.
Premium Gold Caps are 100% made in Japan; these solid capacitors are sleek, high gloss caps with a premium gold coating representing long life Premium Gold and stable performance.
More Precise, More Efficient
By adopting digital pulse-width modulation (PWM), the ASRock motherboard can provide CPU Vcore voltage more efficiently and smoothly. Compared to analog PWM, digital PWM can optimize the CPU power solution and provide a proper and stable Vcore for the processor.
Designed with a 12 Power Phase design, this motherboard features sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
Dual-Stack MOSFET (DSM) is an innovative new design of MOSFETs. The silicon die area is increased by stacking two dies into a MOSFET. The larger the die area, the lower Rds(on). Compared to traditional discrete MOSFET, DSM can provide larger die area and lower Rds(on), so the power supply for CPU Vcore is more efficient.
Dual LAN with Teaming function enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective.
4K is a new standard for display resolutions with a minimum of 3840 x 2160 pixels, which is twice the horizontal and vertical resolution of the 1080p format and four times as many pixels overall.
A-Tuning is ASRock's multi purpose software suite with a new interface, more new features and improved utilities, including XFast RAM, OC Tweaker and a whole lot more.
This motherboard supports Triple Monitor. You may choose up to three display interfaces to connect monitors and use them simultaneously.
DTS Connect is a blanket name for a two-part system, including DTS Interactive and DTS Neo:PC, it is used on the computer platform only, in order to convert PC audio into the DTS format. DTS, DTS-HD, the Symbol, & DTS or DTS-HD and the Symbol together are registered trademarks of DTS, Inc. © DTS, Inc. All Rights Reserved.
ASRock's new pin design for the memory slots may appear to be the same as former designs, but actually effectively reduces distortion and promotes performance, because we strive for perfection even in the most trivial details.
This motherboard comes with a front USB 3.0 panel which not only provides connection for two USB 3.0 ports but also serves as a 2.5" HDD/SDD rack.
