| Brand | EVGA |
|---|---|
| Model | 132-SE-E775-K2 |
| CPU Socket Type | LGA 2011 |
|---|---|
| CPU Type | Core i7 (LGA2011) |
| Chipset | Intel X79 |
|---|
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 2133/1866/1600/1333/1066 |
| Maximum Memory Supported | 32GB |
| Channel Supported | Quad Channel |
| PCI Express 3.0 x16 | 3 (1x16, 2x16 or 3x8 ) |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| SATA 3Gb/s | 4 x SATA 3Gb/s |
|---|---|
| SATA 6Gb/s | 2 x SATA 6Gb/s |
| SATA RAID | 4 x SATA 3Gb/s Support for RAID 0/1/0+1/5/10/JBOD 2 x SATA 6Gb/s Support for Raid 0/1. |
| Audio Chipset | Realtek ALC898 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Marvell 88E8059 |
|---|---|
| Max LAN Speed | 10/100/1000Mbps |
| PS/2 | 1 |
|---|---|
| USB 3.0 | 4 x USB 3.0 |
| USB 1.1/2.0 | 2 x USB 2.0 |
| eSATA | 2 x eSATA 3Gb/s |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 5 Ports |
| Onboard USB | 8 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x 1394b |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | Intel X79 Express Chipset E-LEET Software Support 4 DIMM Quad-Channel DDR3 2133MHz+ (up to 32GB) EVGA EVBot Support 8 Channel High Definition Audio + Optical Dual BIOS Support 100% Solid State- Capacitors EZ Voltage Read Points 6+2 Phase PWM Onboard CPU Temp Monitor PCI Express 3.0 Ready CLEAR CMOS, Power and Reset |
|---|
| Date First Available | June 15, 2012 |
|---|
Pros: Let me just preface this by saying......I'm poor.......really poor. When this came up around Christmas time for about $79.00 after rebate, I said "oh well so the kids miss a couple of meals. I couldn't pass up the chance to get into an x79 board for so little money. EVGA did send the rebate in a timely manner so I am very happy with the whole buying experience and am happy with the operation of this board. My hungry kids however are not.
Cons: My kids went hungry for a bit.
Overall Review: It's now late June and I finally scraped enough money together to go down to my local big brick and mortar, you know, the one that sells processors really cheap to bring you in the store. I bought my I7 3820 processor and ran out because I didn't want to get tempted to buy anything else because I had no extra money. I'm poor, I probably already mentioned that. Anyhow.....I'm in the x79 family and my kids didn't lose that much weight so it's all good.
