Ports Spec: 1 x USB 2.0 (front) with 5V/1.5A fast-charging
3 x USB 3.2 Gen 2 (back) supporting 5V/0.9A
1 x 3.5mm Combo Microphone & Headphone Port (front)
4 x Thunderbolt 4 Ports (1 x upstream and 3 x downstream)
1 x Ethernet
1 x SD Card Reader (UHS-II, SD4.0)
Compatibility: Software
OS Compatibility Windows 7, 8, 8.1, 10
Mac OS 10.11 to 10.12
Ports Spec: 2 x DisplayPort (20 pin) Female
1 x HDMI (19 pin) Female
2 x USB Type-C (24 pin) USB 3.0 Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 x USB Type-A (9 pin) USB 3.0 Female
1 x RJ-45 Female
1 x 3.5 mm Mini-Jack (4 Position) Female
2 x 3.5 mm Mini-Jack (3 Position) Female
1 x Security Lock Slot Female
Compatibility: System Requirements:
Intel Core i7 reccomended
4GB Memory
USB 3.0/3.1 port (Type A or C)
Supported Operating Systems:
Windows 10
Windows 8.1
Windows 7
OS X
Ports Spec: Supports 2 x Displays via HDMI or DisplayPort
6 x USB 3.0 Ports
2 Chanel Headphone Jack
Audio Line In (Microphone)
Gigabit Ethernet - RJ 45 (10/100/1000)
Built In USB 3.0 GPU, plug and play certified by DisplayLink
Weight: 1.95
Features: Supports dual displays with resolutions up to 4096 x 2160 @ 60 Hz (4K).
Ideal for graphic and web designers, animators, CAD engineers, and professionals who work with highly detailed graphics.
The ability to scale your desktop across multiple displays makes this dock perfect for government, finance, medical imagery, marketing and sales
Compatibility: OS Compatibility:
Windows 7, 8, 8.1, 10
macOS 10.11 - 10.12, 10.14
Chrome OS v55+
Ports Spec: 1 x DisplayPort (20 pin) Female
1 x HDMI (19 pin) Female
1 x USB Type-C (24 pin) USB 3.0 Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
3 x USB Type-A (9 pin) USB 3.0 Female
1 x Ethernet Gigabit Female
1 x 3.5 mm Mini-Jack (4 Position) Female
1 x SD / MMC Slot Female
Additional Features: With a single USB connection, Logitech Swytch links a laptop to the room’s display, camera, and audio devices. Now, people can use meeting rooms with any video conferencing software, webinar platform, or streaming service.
Specification: SYSTEM REQUIREMENTS
- Meeting Room Equipment
Display: HDMI input
Conference Camera: USB conference camera with speakerphone
- Laptop Computers
USB 3.0 Port: Type A or Type C
USB Power Delivery: Up to 60 watts for compatible laptops that charge via USB Type C
Operating Systems with DisplayLink Plug and Display Drivers: Windows 10, macOS 10.15 and later, and Chrome OS 75 or later.
INSIDE THE BOX
Swytch Hub
Swytch Extender
Swytch Connector with 1.5m / 4.9ft USB Cable
100-240v Swytch Hub Power Supply
100-240v Swytch Extender Power Supply
5m / 16.4ft USB 3.0 Cabl...
Specifications: 4K Support: Yes
Bus Type: USB-C
USB 3.0
Chipset ID: DisplayLink - DL-6950
Genesys Logic - GL850G
Texas Instruments - TPS65982
Parade Technologies - PS176
VIA Labs - VL813
Realtek - RTL8153
Displays Supported: 1
Fast-Charge Port(s): Yes
Industry Standards:
USB Power Delivery Specification Rev. 2.0
USB Battery Charging Specification Rev. 1.2
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 3840 x 2160p (4K) @ 30Hz
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Center Tip Polarity: Positive
Input Current: 2 A
Input Voltage: 100 - 240 AC
Output Current: 6 A
Output Volta...
