Features: 230V 32A metered Power Distribution Unit (PDU) in 2U horizontal rackmount form factor
32A maximum capacity
Attached Blue IEC-309 32A input plug with 12 ft. / 3.6m line cord
18 total output receptacles (16 C13, 2 C19)
Outlets are arranged in two separately breakered and metered 16A load banks (each with 8 C13 and 1 C19 outlet)
Current meters offer the ability to visually monitor power consumption levels to prevent mains, generator, UPS or PDU overloads and to ensure proper load balance in complex redundant power applications
Pair of easy to read, two-character LED displays offer continuous PDU current monitoring data in one-amp increments for each metered load bank
Circuit breakers offer protection from overloads a...
Features: Output Receptacles:16 x NEMA 5-20R
Product Name:ePDU Metered 16-Outlet PDU
Form Factor:Horizontal Rackmount
Input Receptacles:1 x NEMA L5-30P
Power Rating:2.88 kVA
Power Rating:2.88 kVA
Form Factor:Horizontal Rackmount
Product Type:PDU
Certifications: Tested to UL60950-1:2007 (USA), CAN/CSA-C22.2 NO. 60950-1: 2005 (Canada), CE (International), FCC Class A (Emissions), NOM (Mexico), RoHS compliant, TAA compliant
Features: Package Contents:
5-Outlets 3kVA PDU
Rack Mounting Brackets
User Manual
Number of Output Connections:1
4
Output Receptacles:1 x NEMA L5-30R
4 x NEMA 5-20R
Power Rating:3 kVA
Power Rating:3 kVA
Current:30 A Input Current Per Phase
30 A Line Current Per Phase
30 A Total Current Draw Per Phase
Product Name:5-Outlets 3kVA PDU
Input Receptacles:NEMA L5-30P
Product Type:PDU
Form Factor:Rack-mountable
Dimensions: 3.5" Height x 17.0" Width x 3.0" Depth
Features: Package Contents:
Basic Rack 3680VA PDU
Installation Guide
Toolless Mounting Kit
Current:16 A Input Current
16 A Output Current
Number of Output Connections:20
4
Output Receptacles:20 x IEC 320-C13
4 x IEC 320-C19
Power Rating:3.68 kVA
Power Rating:3.68 kVA
Product Name:Basic Rack 3680VA PDU
Color:Black
Input Receptacles:IEC 320-C20
Product Type:PDU
Form Factor:Zero U
Form Factor:Zero U Rack-mountable
Dimensions: 64.0" Height x 2.2" Width x 1.7" Depth
Features: Power Rating:8.64 kVA
Form Factor:Rack-mountable
Product Type:PDU
Power Rating:8.64 kVA
Form Factor:Rack-mountable
Input Receptacles:NEMA L21-20P
Product Name:ePDU 37-Outlets PDU
Output Receptacles:1 x NEMA 5-20R
30 x IEC 60320 C13
6 x IEC 60320 C19
Features: Number of Output Connections:20
Power Rating:4.90 kVA
Product Type:PDU
Current:24 A
Power Rating:4.90 kVA
Form Factor:Rack-mountable
Input Receptacles:NEMA L6-30P
Product Name:4.9kVA 208 Volt 20 Outlet NA/JP Basic Power Distribution Unit
Output Receptacles:20 x IEC 60320 C13
