Features: • 1 x 10G PoE++ port (Data + PoE out)
• 1 x 10G port (Data in)
• 120W PoE power budget
• Supports PoE (15.4W), PoE+ (30W), and PoE++ (95W) devices
• Uses IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt industry PoE standards for greater device interoperability
• Network a PoE device located up to 100m (328 ft.)
• Fanless design eliminates operating noise and lowers energy consumption
• Extreme operating temperature range -40° – 75° C (-40° – 167° F)
• Includes DIN-Rail mount and wall mount
• Power supply sold separately (model: TI-S15052)
• NDAA / TAA compliant (U.S. and Canada only)
Features: • 8 x Fast Ethernet PoE+ ports
• Up to 200W PoE power budget
• Hardened IP50 rated metal switch
• Extreme operating temperature range of -40° – 75°C (-40° – 167°F)
• Dual inputs provide redundant power with overload current protection
• 1.6Gbps switching capacity
• Alarm relay triggered by power failure
• Includes DIN-Rail mount and wall mount brackets
• Power supply sold separately (model:
Features: • Includes one MoCA 2.5Gbps Ethernet over Coax Adapter (TMO-313C)
• Supports MoCA® 2.5 over coaxial cables
• 1 x MoCA Coax: F-Type Female coax input
• 1 x 2.5Gbps RJ45 LAN port
• Backward compatible with MoCA 2.0/1.1/1.0 standards
• Supports up to 16 nodes on one network
• Bonded MoCA 2.5 channels provide a net throughput of up to 2.5Gbps
• Designed to
Features: • 4 x Fast Ethernet PoE+ ports
• 1 x Fast Ethernet port
• Up to 90W PoE power budget
• 1Gbps switching capacity
• Hardened IP50 rated aluminum switch
• Extreme operating temperature range of -40° – 75°C (-40° – 167°F)
• Dual inputs provide redundant power with overload current protection
• Includes DIN-Rail mount and wall mount brackets
• Power supply sold separately (model: TI-S15052)
• NDAA
Features: • 8 x M12 (X-code) Gigabit PoE+ ports
• 2 x M12 (X-code) Gigabit port with Bypass function
• 1 x M12 (A-code) power port
• PoE power budget: 200W @ 56V DC / 100W @ 24V DC
• EN 50155 compliant for rolling stock and railway applications
• Hardened IP40 rated metal housing
• 20Gbps switching capacity
• Operating temperature range of -40° –
Features: • 8 x Gigabit PoE+ ports
• 200W PoE power budget
• 16Gbps switching capacity
• Supports jumbo frames up to 9KB
• Hardened IP40 rated metal housing
• Includes DIN-Rail bracket and magnetic wall mount kit
• Operating temperature range of -40° – 75° C (-40° – 167° F)
Features: • 1 x Gigabit port
• 1 x 100/1000Mbps SFP port
• Up to 120W PoE power budget
• Hardened IP50 rated metal switch
• Extreme operating temperature range of -40° – 75°C (-40° – 167°F)
• Dual inputs provide redundant power with overload current protection
• Alarm relay triggered by power failure
• 12Gbps switching capacity
•
