Specifications: Connector(s):
1 - Drive Connectors: M.2 (PCIe, SATA, M-Key, NGFF)
1 - Host Connectors: USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps)
Interface: USB 3.1 Gen 2
Bus Type: USB 3.2 Gen 2 10Gbps
Number of Drives: 1
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
Drive Installation: Fixed
Compatible Drive Types: M.2 SATA (NGFF, B+M-Key)
Supported Drive Height(s):
2230
2242
2260
2280
Chipset ID: Realtek - RTL9210B
1 - LED Indicators: Power & Activity
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
UASP Support: Yes
TRIM Support: Yes
4Kn Support: Yes
Type and Rate: NVMe (PCIe Gen 3)
Insertion Rating:
USB-C: 10,000 cycles
M.2: 60 Cycles
General Specifications: Fully compatible with M.2 SATA, AHCI and PCIe NVMe based drive...
Dimensions: 110mm (W) x 9mm (H) x 26mm (D) / 4.33" (W) x 0.35" (H) x 1.02" (D)
Specifications: To take advantage of the increased popularity of M.2 solid state drives, SilverStone created the MS09, a premium, pocketable M.2 enclosure. It has an exquisite anodized aluminum exterior with a size that is nearly as small as common USB thumb drives. Internally, it fits M.2 SATA SSD up to 80mm so the MS09 can be used with a wide variety of new or repurposed M.2 SATA SSD from laptops and turning them into high-speed USB flash drive. To make the most of M.2 SATA SSD’s performance, it also incorporates USB 3.1 Gen 2 interface for superfast read / write and excellent compatibility. Lastly, the MS09 is designed to work without additional driver installation so you can conveniently take it anywhere and use it on nearly any PC instantly.
Data tr...
