Frequency Band: 2.4Ghz: 1-13
5Ghz: 36-64, 100-144, 149-165
Part Number: 9U1-H550-US00
Standards: IEEE 802.11a/b/g/n/ac/ax
Supported rates:
802.11ax: 4 to 1,774 Mbps (MCS0 to MCS11, NSS=1 to 2 for HE 20/40/80)
802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2 for VHT 20/40/80)
802.11n: 6.5 Mbps to 300 Mbps (MCS0 to MCS15)
802.11a/g: 6 to 54 Mbps
802.11b: 1 to 11 Mbps
Standard Compliance:
EN 60950-1 Safety
EN 60601-1-2 Medical
EN 61000-4-2/3/5 Immunity
EN 50121-1 Railway EMC
EN 50121-4 Railway Immunity
IEC 61373 Railway Shock & (bbr-?on
EN 62311 Human Safety/RF Exposure
WEEE & RoHS
ISTA 2A Transportation
Antenna: Antenna Type: BeamFlex+ adaptive antennas with polarization diversity and adaptive antenna that provides multiple unique antenna patterns
Antenna Gain (max) · Up to 1dBi
Peak Transmit Power (aggregate acr...
