Memory Standard: DDR4 3200(O.C.)/ 2933(O.C.)/ 2667*/ 2400/ 2133
* Support for higher than DDR4 2667 MHz may vary by CPU.
PCI Express 3.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Actual support may vary by CPU.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x4 (PCIEX4)
Memory Standard: AMD Ryzen Processors
DDR4 3200(O.C.)/ 2933(O.C.)/ 2666/ 2400/ 2133*1
AMD 7th Generation A-series/ Athlon Processors
DDR4 2400/ 2133
*1 Due to the limitation of AMD Ryzen processors, memory frequencies higher than DDR4 2666 MHz are supported only when using one DIMM per channel.
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Memory Standard: Ryzen Processors: DDR4 3200(O.C.)/ 2933(O.C.)/ 2666/ 2400/ 2133 *1
7th Gen. A-series/ Athlon Processors: DDR4 2400/ 2133
*1 Due to AMD Ryzen Processor limitation, More than DDR4-2666 is supported by one DIMM per channel only.
Onboard Video Chipset: Integrated AMD Radeon R Series Graphics in the 7th Generation A-Series APU
Multi-VGA output support: HDMI/DVI/RGB ports
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
Maximum shared memory of 2048MB
Memory Standard: DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866*
* 7th Gen A-series/ Athlon processors support up to DDR 2400 MHz only. Please refer MSI for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slots
- RYZEN series processors support x16 mode
- 7th Gen A-series/ Athlon processors support x8 mode
Onboard Video Chipset: Onboard Graphics:
- 1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz*
- 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz*
- 1 x HDMI port, supports a maximum resolution of 4096x2160@24Hz*
* Only support when using a 7th Gen A-series / Athlon processor.
** Maximum shared memory of 2048MB.
Memory Standard: DDR4 3200(O.C.)/ 2933(O.C.)/ 2667*/ 2400/ 2133
* Support for higher than DDR4 2667 MHz may vary by CPU.
PCI Express 3.0 x16: 1 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
Onboard Video Chipset: Integrated Graphics Processor:
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version.
1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
* Support for HDMI 1.4 version.
Maximum shared memory of 2GB
* Actual support may vary by CPU.
Memory Standard: Support for DDR4 3200(O.C.)/ 2933(O.C.)/ 2667*/ 2400/ 2133 MHz memory modules
* Actual support may vary by CPU.
PCI Express 3.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* Actual support may vary by CPU.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
Onboard Video Chipset: Integrated Graphics Processor:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60Hz
* The DVI-D port does not support D-Sub connection by adapter.
1 x HDMI port, supporting a maximum resolution of 4096x2160@24Hz
* Support for HDMI 1.4 version.
Maximum shared memory of 2GB
* Actual support may vary by CPU.
Memory Standard: DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866 *
* 7th Gen A-series/ Athlon processors support up to 2400 MHz. Please refer MSI site for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E2)
- Supports x16 speed with RYZEN Series Processors
- Supports x8 speed with 7th Gen A-series/ Athlon processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
* PCI_E4 slot will become PCIe 2.0 x2 mode, when installing device in any PCIe x1 slot.
Memory Standard: AMD Ryzen Processors
4 x DIMM, Max. 64GB, DDR4 3200(O.C.)/ 2933(O.C.)/ 2666/ 2400/ 2133*
AMD 7th Generation A-series/ Athlon Processors
4 x DIMM, Max. 4GB, DDR4 2400/ 2133
* Due to the limitation of AMD Ryzen processors, memory frequencies higher than DDR4 2666 MHz are supported only when using one DIMM per channel.
** Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
** Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Memory Standard: DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866
* 7th Gen A-series/Athlon processors support up to 2400 MHz. Please refer www.msi.com for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E2)
- Supports x16 speed with RYZEN Series Processors
- Supports x8 speed with 7th Gen A-series/Athlon processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
* PCI_E4 slot will become PCIe 2.0 x2 mode, when installing device in any PCIe x1 slot.
Memory Standard: DDR4 3200(OC)/ 2933(OC)/ 2667/ 2400/ 2133/ 1866 MHz*
* A-series / Athlon X4 processors support up to DDR 2400 MHz only. Please refer www.msi.com for more information on compatible memory
* Please refer www.msi.com for more information on compatible memory
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slots
- Supports x16 speed with RYZEN Series Processors
- Supports x8 speed with AMD Ryzen with Radeon Vega Graphics and A-series / Athlon X4 Processors
- Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz(*1,3)
1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz(*1,2,3)
1. Only support when using AMD Ryzen with Rade...
Memory Standard: AMD Ryzen Processors
DDR4 3200(O.C.)/ 2933(O.C.)/ 2666/ 2400/ 2133*1
AMD 7th Generation A-series/ Athlon Processors
DDR4 2400/ 2133
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
*1 Due to the limitation of AMD Ryzen processors, memory frequencies higher than DDR4 2666 MHz are supported only when using one DIMM Per Channel.
Onboard Video Chipset: Integrated AMD Radeon R Series Graphics in the 7th Generation A-Series APU *
Multi-VGA output support: DVI-D/RGB ports
- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
Maximum shared memory...
Memory Standard: DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866*
* A-series / Athlon X4 processors support up to 2400 MHz. Please refer www.msi.com for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E2)
- Supports x16 speed with RYZEN Series Processors
- Supports x8 speed with AMD Ryzen with Radeon Vega Graphics and A-series / Athlon X4 Processors
- Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
* PCI_E4 slot will support PCIe 2.0 x2 only, when installing device in any PCIe x1 slot.
Memory Standard: AMD Ryzen series CPUs support DDR4 3200+(OC)/ 2933(OC)/ 2667/ 2400/ 2133 *
AMD 7th Gen A-Series APUs support DDR4 2400/ 2133 *
* Please refer to Memory Support List on ASRock's website for more information.
PCI Express 3.0 x16: AMD Ryzen series CPUs
2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE2); dual at x16 (PCIE2) / x4 (PCIE4))*
AMD 7th A-Series APUs
2 x PCI Express 3.0 x16 Slots (single at x8 (PCIE2); dual at x8 (PCIE2) / x2 (PCIE4))*
*Supports NVMe SSD as boot disks
*If M2_1 is occupied, PCIE4 will be disabled.
Onboard Video Chipset: Integrated AMD Radeon R-Series Graphics in A-series APU*
- DirectX 12, Pixel Shader 5.0
- Max. shared memory 2GB
- Three graphics output options: D-Sub, DVI-D and HDMI
- Supports Triple Monitor
- Supports HDMI with max. resolution up to 4K x 2K...
Memory Standard: DDR4 3200(O.C.)/ 2933(O.C.)/ 2667*/ 2400/ 2133
* Support for higher than DDR4 2667 MHz may vary by CPU.
PCI Express 3.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
* Actual support may vary by CPU.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2/PCIEX1_3 slot is populated. The PCIEX4 slot operates at up to x4 mode when both of the PCIEX1_2 and PCIEX1_3 slots are empty.
* Actual support may vary by CPU.
1 x PCI Express x16 slot, running at...
Memory Standard: DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866
* A-series / Athlon X4 processors support up to 2400 MHz. Please refer www.msi.com for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E2)
- Supports x8 speed with AMD Ryzen with Radeon Vega Graphics and A-series / Athlon X4 Processors
- Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
* PCI_E4 slot will become PCIe 2.0 x2 mode, when installing device in any PCIe x1 slot.
Memory Standard: DDR4 3200(O.C.)/ 2933(O.C.)/ 2667*/ 2400/ 2133
* Actual support may vary by CPU.
PCI Express 3.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
* Actual support may vary by CPU.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x4 (PCIEX4)
Memory Standard: DDR4 3200(O.C.)/ 2933(O.C.)/ 2667*/ 2400/ 2133
* Support for higher than DDR4 2667 MHz may vary by CPU.
PCI Express 3.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
* Actual support may vary by CPU.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2/PCIEX1_3 slot is populated. The PCIEX4 slot operates at up to x4 mode when both of the PCIEX1_2 and PCIEX1_3 slots are empty.
* Actual support may vary by CPU.
Memory Standard: DDR4 3200(OC)/ 2933(OC)/ 2667/ 2400/ 2133/ 1866 MHz*
* 7th Gen A-series/Athlon processors support a maximum of DDR4 2400 MHz.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slots
- RYZEN series processors support x16 mode
- 7th Gen A-series/Athlon processors support x8 mode
Onboard Video Chipset: Supported only by CPU with integrated graphic:
1 x HDMI port, supports a maximum resolution of 4096x2160@24Hz*
1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz
* Only support when using a 7th Gen A-series/Athlon processor
* Maximum shared memory of 2048MB
PCI Express 3.0 x16: 1 x PCI Express x16 slot, running at x16 (PCIEX16)
For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Actual support may vary by CPU.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
PCI Express 2.0 x16: 1 x PCI Express x16 slot, running at x4 (PCIEX4)
The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2/PCIEX1_3 slot is populated. The PCIEX4 slot operates at up to x4 mode when both of the PCIEX1_2 and PCIEX1_3 slots are empty.
Actual support may vary by CPU.
1 x PCI Express x16 slot, running at x1 (PCIEX1_3)
Memory Standard: Supports DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866 *
* 7th Gen A-series/ Athlon processors support up to 2400 MHz. Please refer MSI for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E2)
- Supports x16 speed with RYZEN Series Processors
- Supports x8 speed with 7th Gen A-series/ Athlon processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
* PCI_E4 slot will become PCIe 2.0 x2 mode, when installing device in any PCIe x1 slot.
Memory Standard: Supports DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866 *
* 7th Gen A-series/ Athlon processors support up to 2400 MHz. Please refer MSI for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot
- RYZEN series processors support x16 mode
- 7th Gen A-series/ Athlon processors support x8 mode
Onboard Video Chipset: Onboard Graphics
1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz
1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz*
1 x HDMI port, supports a maximum resolution of 4096x2160@24Hz*
* Only support when using a 7th Gen A-series/ Athlon processor
* Maximum shared memory of 2048MB
Memory Standard: DDR4 3200(OC)+/ 2933(OC)/ 2667(OC)/ 2400/ 2133/ 1866
* A-series / Athlon X4 processors support up to 2400 MHz. Please refer www.msi.com for more information on compatible memory.
PCI Express 3.0 x16: 1 x PCIe 3.0 x16 slot (PCI_E2)
- Supports x8 speed with AMD Ryzen with Radeon Vega Graphics and A-series / Athlon X4 Processors
- Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
PCI Express 2.0 x16: 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)*
* PCI_E4 slot will become PCIe 2.0 x2 mode, when installing device in any PCIe x1 slot.
