Specifications: Interfaces:
Telephone Interfaces Two (2) FXS ports
Network Interfaces One (1) 10/100 Mbps auto-sensing ethernet ports (RJ45)
LED Indicators POWER, INTERNET, PHONE1, PHONE2
Factory Reset Button Yes
Voice, Fax, Modem:
Telephony Features Caller ID display or block, call waiting, flash, blind or attended transfer, forward,
hold, do not disturb, 3-way conference
Voice Codecs G.711 with Annex I (PLC) and Annex II (VAD / CNG), G.723.1, G.729A/B, G.726, iLBC,
OPUS, dynamic jitter buffer, advanced line echo cancellation
Fax Over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax
Pass-through
Short / Long Haul Ring Load 2 REN: Up to 1 km on 24 AWG
Caller ID Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID
Disconnect Methods Busy Tone, Polarity Reversal / Wink, Loop Current
Signaling:
Network Protocols...
Specifications: Interfaces/Ports
PoE (RJ-45) Port:
No
USB:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of FXS (RJ-11) Ports:
2
I/O Expansions
SIM Card Supported:
No
Network & Communication
Ethernet Technology:
Fast Ethernet
Network Standard:
10/100Base-T
Wireless Specifications
Wireless LAN:
No
Power Description
Redundant Power Supply Supported:
No
Physical Characteristics
Form Factor:
Wall Mountable
Desktop
Height:
3.9"
Width:
3.9"
Depth:
1.1"
Weight (Approximate):
4.70 oz
Specifications: Interfaces/Ports
PoE (RJ-45) Port:
No
USB:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of FXS (RJ-11) Ports:
2
I/O Expansions
SIM Card Supported:
No
Network & Communication
Ethernet Technology:
Fast Ethernet
Network Standard:
10/100Base-T
Wireless Specifications
Wireless LAN:
No
Power Description
Redundant Power Supply Supported:
No
Physical Characteristics
Form Factor:
Wall Mountable
Desktop
Height:
3.9"
Width:
3.9"
Depth:
1"
Weight (Approximate):
4.70 oz
Features: Interfaces/Ports
Number of Network (RJ-45) Ports:
2
Number of FXS (RJ-11) Ports:
2
I/O Expansions
SIM Card Supported:
No
Network & Communication
Ethernet Technology:
Fast Ethernet
Network Standard:
10/100Base-T
Wireless Specifications
Wireless LAN:
No
Power Description
Redundant Power Supply Supported:
No
Specifications: Pro3000 Analog Toner Specifications
User interface:
Slide switch selects Continuity or Tone Mode
Push button switch selects SOLID, ALT or OFF
Tone mode LED
Continuity/Polarity LED
Solid Frequency: 1000 Hz nominal
Alternating Frequency: 1000/1500 Hz nominal
Over Voltage Protection: 60 Vdc in Toner/Polarity Mode
Output Power in Tone Mode: 8 dbm into 600 ohms
Output Voltage Level in Continuity Mode: 8 Vdc with fresh battery
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Pro3000 Analog Probe specifications
User interface:
ON/OFF pushbutton
Volume dial
Replaceable tip
3.5 mm earphone jack
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Specifications: These kits contain essential industry standard telecommunications tools and test equipment.
D814 industry standard punchdown tool for reliable terminations
EverSharp 66/110 cut blade provides flexibility for different block and jack terminations
Cable Stripper quickly rings and slits many types of cable
Use the Probe Pic to check for loose or damaged connections
Cut and strip wire cleaner and faster with the Electricians D-Snips
Connect to jacks for testing with the standard 4-Wire Modular Adapter
A soft zippered pouch keeps your tools all in one convenient place
Fluke Networks' Electrical Contractor Telecom Kits are comprised of industry standard telecommunications tools and test equipment, in a durable cordura case. The kits are designed for technicians who install, test and troubleshoot phone and data lines.
Includes a Pro3000 Analog Ton...
Specification: Wideband IP Paging Adapter & Bell Scheduler for Integrating Legacy Analog Amplifiers – PoE
ENVIRONMENTAL: 0 to + 40° C (32 to 104° F); 10-95% RH non-condensing. Dry indoor locations only.
Audio: MICROPHONE: Connection available for external microphone
AUDIO MEMORY & FORMAT: 1 GByte audio storage for WAV or MP3 files
AUDIO CONTROLS: Volume, AGC, Latency, LF Cut
ANTI-FEEDBACK DELAY: Cache to memory and release
AUDIO DELAY: Programmable 1-1000 ms synchronization delay
Frequency Band: Wireless mic: 1921.536 - 1928.448 MHz
Base unit: 1921.536 - 1928.448 MHz
: Automatic gain control
2-line backlit display with date and time
Wireless microphone battery low indicator; flashing LED
Wireless microphone auto power off; when base powered off
Connects to / supports one analog line; POTS interface
10 ring tones / melodies; 6 ring levels
Eco mode (talk mode)
10 speed dial entries
Redial/last number redial
Pre-dialing with editing
Mute indicator; red
: Wireless mic: Ni-MH battery pack; 2.4V; 400 mAh rechargeable battery
Base unit adapter: Input: 100 - 240V AC 50/60 Hz
Output: 9V DC @ 1500 mA
