Specifications: AC Power
Line Voltage: 120V, 60Hz
Voltage Regulation: No
Total Current Capacity: 15 A (1800 W)
Protection Modes: L-N, L-G, N-G
Initial Clamping Level: 200V Peak, 141V RMS
Energy Dissipation: 2125 Joules
Peak Impulse Current: 75,000 Amps
Catastrophic Surge Circuit: Yes
Thermal Fusing: Yes
Auto-resetting Over-voltage shutoff: 142 VAC +/- 8 VAC
Auto-resetting Under-voltage shutoff: 86 VAC +/- 6 VAC
EMI/RFI Noise Filtration
Bank 1: Up to -86 db (100 KHz - 2 MHz)
Bank 2: Up to -91 db (100 KHz - 2 MHz)
Bank 3: Up to -81 db (100 KHz - 2 MHz)
Bank 4: Up to -100 db (100 KHz - 2 MHz)
Bank 5, High Current Outlets: Up to -81 db (100 KHz - 2 MHz)
DC Trigger Input
Jacks: 3.5mm (1/8") mono mini-plug
Voltage and Polarity: 3 - 24V DC, bidirectional
Current Requiremen...
Specifications: Current: 15 A
Frequency: 60 Hz
Input Voltage: 120 V AC
Plug/Connector Type: NEMA 5-15P
Protection Type: AC Noise, EMI / RFI, Inrush Current, Over Voltage, Surge, Under Voltage, Wiring Fault, Zero Voltage Turn-on
Receptacles: 3 x NEMA 5-15R
Specifications: Load Rating: 20 amps @ 120 volts
Maximum Load Inrush Energy: 1400 Joules total during power-up
UL 1449 Adjunct Classification Test Results: 1000 surges, 6000 volts, 3000 amps, B3 pulse; Measured suppressed voltage: 170 volts; no failures
Federal Guidelines: Grade A, Class 1, Mode 1(CID A-A-55818)
EMI/RFI Filter, Normal Mode (50-ohm load): > 30 dB 100 KHz - 50 MHz
EMI/RFI Filter, Common Mode (50-ohm load): > 20 dB 1 MHz - 50 MHz
Under-Voltage Auto Shutdown: Adjustable from 90V to 110V
Over-Voltage Auto Shutdown: Adjustable from 130V to 150V
Endurance (C62.41-1991 Category B3 pulses): 1 kV>500,000; 3 kV>10,000; 6 kV>1000
Control Inputs: Momentary Switch, Latching Switch,Contact Closure or 5-30 Vdc
Input Control Current: 3 mA
DC Voltage Output: 12 Vdc, 40 mA maximum load
Auxiliary Relay Cont...
Specifications: Surge Protection and Filtering
Surge energy rate: 340 J
Noise suppression
Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
Let through voltage rating: 330 V
Main Input Voltage
120 V
Main Output Voltage
120 V
Rated power in W
390 W
rated power in VA
650 VA
Product or component type
Uninterruptible power supply (UPS)
Input Connection Type
NEMA 5-15P
output connection type
4 NEMA 5-15R
4 NEMA 5-15R surge
Cable length
1.5 m
Number of cables
1
Battery type
Lead-acid battery
Provided equipment
User manual
USB cable
Range of product
Back-UPS
Input
Network frequency
60 Hz +/- 3 Hz
Input voltage limits
90...140 V
Maximum input current
12 A
Output
Maximum configur...
Specifications: Protection Type:
Line to Neutral
Spike
AC Noise
AC Surge
Receptacles: 9
Input Voltage: 110 V AC
Current:
15 A
12 kA Peak Impulse Current
Frequency: 60 Hz
Surge Energy Rating: 170 J
