Specifications: Support Drive Size: 1 x M / B + M key M.2 PCIe NVMe SSD 2230/2242/2260/2280
Compatible Drive Type: NVMe M.2
Number of M.2: 1
Host Interface: 1 x SFF-8639
Transfer Rate: Up to 32Gbps
Support HDD Capacity: No Limitation
Structure / Material: Metal & ABS Plastic
Support Hot-Swap: Yes
Product Dimension (W x H x D): 2.76" x 0.37" x 3.98"
Product Net Weight: 0.15 lb.
SATA Connector Insertion Rate: 10,000
Humidity: 5%~65% RH
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -35°C to 70°C (-31°F to 158°F)
Compliance: CE, RoHS, REACH
Specifications: IOCrest SI-ADA40121 provides the capability to utilize an Intel 750 Series 2.5" NVMe SSD (SFF-8639). Comes with PCIe 3.0 x4 (12 Gbps) bandwidth that can be used if motherboard comes with M.2 M-key slot. Otherwise M.2 adapter will be needed.
Operating Systems Supported: Windows 7/8/8.1/10 64-Bit, UEFI 2.3.1 or later
Specifications: Built in M.2 M-Key Recep5cal Connector
PCI Express Base Specifica5on Rev 3.0
NVM Express 1.2a
3.3v, 5A maximum output current
Short Circuit Protec5on
Thermal Shutdown Protec5on
Windows 7/8/8.1/10 64-Bit
Package Contents: 1 x Adapter
1 x Copper Nut
1 x M3x3 Screw, M3x5 Screw
2 x Washers
1 x SFF-8643 to U.2 Adapter Cable
