Brand | Palit |
---|---|
Model | NE5S4500F0601 |
Interface | PCI Express 2.0 x16 |
---|
Chipset Manufacturer | NVIDIA |
---|---|
GPU | GeForce GTS 450 (Fermi) |
Core Clock | 783MHz |
Shader Clock | 1566MHz |
CUDA Cores | 192 |
Effective Memory Clock | 3608MHz |
---|---|
Memory Size | 1GB |
Memory Interface | 128-Bit |
Memory Type | GDDR5 |
DirectX | DirectX 11 |
---|---|
OpenGL | OpenGL 4.1 |
HDMI | 1 x HDMI 1.4a |
---|---|
DVI | 1 x DVI |
RAMDAC | 400MHz |
---|---|
Max Resolution | 2560 x 1600 |
3D VISION Game Ready | Yes |
Cooler | Single Fan |
System Requirements | Minimum 400W or greater system power supply (with a minimum 12V current rating of 22A) |
Power Connector | 6-Pin |
Dual-Link DVI Supported | Yes |
HDCP Ready | Yes |
Features | NVIDIA CUDA technology with CUDA C/C++ DirectCompute 5.0 and OpenCL support NVIDIA PhysX technology NVIDIA 3D Vision support NVIDIA PureVideo HD technology |
---|
Form Factor | Low Profile Ready |
---|---|
Card Dimensions (L x H) | PCB: 7.48"(L) x 2.72"(W) Cooler: 2 slot Bracket: 2 slot |
Date First Available | September 10, 2010 |
---|
Pros: It's a gts 450. Option for low profile. Actually works well if you don't mind the squeal.
Cons: Loud under load. Like hairdryer loud, a higher pitch than anything else in my living room. I originally purchased this for it's form factor, placing it into a smaller build, though that project was later abandoned entirely. After placing this card into a larger case with better airflow, I was still seeing warmer temps that I would like. I removed the heat sink to re seat with some different paste (This involves tearing a warranty sticker, by the way.) I was less than impressed with what I found. Cheap hunk of metal and bent fins. Some of mine were actually touching each other.
Overall Review: A bit amazed. After the thought and design of a low profile card, they just throw (what appears to be) the cheapest heat sink they could find on this thing. Anyway, after re-seating (and re bending...sigh) the sink I'm running 40's idle and low 80's under load with furmark. Much better than the 90-100's I was running before.
