Brand | PNY |
---|---|
Model | VCG5070T16TFXPB1 |
Interface | PCI Express 5.0 x16 |
---|
Chipset Manufacturer | NVIDIA |
---|---|
GPU Series | NVIDIA GeForce RTX 50 Series |
GPU | GeForce RTX 5070 Ti |
Architecture | Blackwell |
CUDA Cores | 8960 Cores |
Effective Memory Clock | 28000 MHz (28 Gbps) |
---|---|
Memory Size | 16GB |
Memory Interface | 256-Bit |
Memory Type | GDDR7 |
Multi-Monitor Support | 4 |
---|---|
HDMI | 1 x HDMI 2.1b |
DisplayPort | 3 x DisplayPort 2.1b |
Color | Black |
---|---|
DLSS Support | DLSS 4.0 |
Max Resolution | 7680 x 4320 |
Virtual Reality Ready | Yes |
Cooler | Triple Fans |
Thermal Design Power | 300W |
System Requirements | PCI Express-compliant motherboard with one 2.98-width x16 graphics slot Three 8-pin supplementary power connectors Total graphics power 300 W Required system power 750 W Microsoft Windows 11 64-bit, Windows 10 (November 2018 or later) 64-bit, Linux 64-bit Internet connection |
Recommended PSU Wattage | 750W |
Power Connector | 16-pin (One 16-pin to Three 8-pin) |
Form Factor | ATX |
---|---|
Max GPU Length | 300 mm |
Low Profile Bracket Included | No |
Card Dimensions (L x H) | 11.80" x 4.73" x 2.35" |
Slot Width | 2.98 Slots |
Date First Available | August 14, 2025 |
---|
